Carte mère Supermicro X12DAI-N6

  1. 3rd Gen Intel® Xeon® Scalable processors
    Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
  2. Intel® C621A
  3. Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz
    Up to 4TB Intel® Optane™ Persistent Memory, DDR4-3200MHz, in 16 DIMM slots;
  4. 5 PCI-E 4.0 x16,
    1 PCI-E 4.0 x8,
    4 PCI-E 4.0 NVMe x4 Internal Port(s)
    M.2 Interface: 2 PCI-E 4.0 x4, RAID 0 & 1
    M.2 Form Factor: 2280/22110
    M.2 Key: M-Key
  5. Intel® C621A controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  6. Dual LAN with Intel® i210 Gigabit Ethernet Controller
  7. 1 VGA D-Sub Connector port
Product SKUs
MBD-X12DAI-N6
  • X12DAI-N6

Physical Stats
Form Factor
  • E-ATX
Dimension
  • 12" x 13" (30.48cm x 33.02cm)

Processor
CPU
  • 3rd Gen Intel® Xeon® Scalable processors
  • Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s

System Memory
Memory Capacity
  • 16 DIMM slots
  • Up to 4TB Intel® Optane™ Persistent Memory 200 Series, DDR4-3200MHz
  • Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz; Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz
Memory Type
  • 3200/2933/2666MHz ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
DIMM Sizes
  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices
Chipset
  • Intel® C621A
SATA
  • Intel® C621A controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
IPMI
  • ASPEED AST2600 BMC
Audio
  • 7.1 HD Audio
Graphics
  • ASPEED AST2600 BMC
Network Controllers
  • Dual LAN with Intel® i210 Gigabit Ethernet Controller

Input / Output
USB
  • 6 USB 3.2 Gen1 port(s) (2 via header; 4 rear)
  • 2 USB 3.2 Gen2 port(s) (1 via header; 1 rear type A)
Video Output
  • 1 VGA D-Sub Connector port(s)
Serial Port
  • 1 COM Port(s) (1 header)
DOM
  • 2 SuperDOM (Disk on Module) power connector
TPM
  • 1 TPM Header
Expansion Slots
PCI-E
  • 1 PCI-E 4.0 x8,
  • 5 PCI-E 4.0 x16
M.2
  • M.2 Interface: 2 PCI-E 4.0 x4, RAID 0 & 1
  • Form Factor: 2280/22110
  • Key: M-Key

System BIOS
BIOS Type
  • AMI UEFI

Management
Software
  • SuperDoctor® 5, SUM, SPM, Intel® Node Manager, SSM, Watchdog, IPMI (Intelligent Platform Management Interface) v2.0 with KVM support

PC Health Monitoring
Voltage
  • VBAT, System temperature, PCH temperature, Monitors CPU voltages, Memory temperature, CPU temperature, CPU, +5V standby, +5V, +3.3V, +12V, VRM temperature, Memory Voltages, 8 -fan status
LED
  • Power LED
  • BMC/IPMI Heartbeat LED
  • CPU / System Overheat LED
Temperature
  • Monitoring for CPU and chassis environment
  • CPU thermal trip support
FAN
  • 8x 4-pin fan headers (up to 8 fans)
  • PWM fan speed control
  • Status monitoring for speed control
  • 8x fans with tachometer monitoring
Other Features
  • WOL, UID, RoHS, Node Manager Support, CPU thermal trip support for processor protection, Chassis intrusion header, Chassis intrusion detection, ATX Power connector, ACPI power management, RoT, NCSI header

Operating Environment
Operating Temperature Range
  • 10°C - 35°C (50°F - 95°F)
Non-Operating Temperature Range
  • -40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range
  • 8% - 90% (non-condensing)
Non Operating Relative Humidity Range
  • 5% - 95% (non-condensing)
MBD-X12DAI-N6-O
