MBD-H12DSI-N6-O Supermicro

MBD-H12DSI-N6-O

1.Dual AMD EPYC™ 7003/7002 Series Processors
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)

2.4TB Registered ECC DDR4 3200MHz SDRAM in 16 DIMMs

3.Expansion slots:
3 PCI-E 4.0 x16 slots, 3 PCI-E 4.0 x8 slots
M.2 Interface: 1 PCI-E 4.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-key

4.10 SATA3, 2 SATADOM, 4 NVMe

5.Dual Gigabit LAN ports,
1 dedicated IPMI LAN Port

6.ASPEED AST2600 BMC graphics

7.2 USB 2.0 ports (rear),
4 USB 3.0 ports (2 rear, 2 headers)

8.8x 4-pin PWM Fans & Speed control



Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Product SKUs
MBD-H12DSi-N6
  • H12DSi-N6

Physical Stats
Form Factor
  • EATX
Dimensions
  • 12" x 13.05" (30.5cm x 33.1cm)

Processor/Chipset
CPU
  • Dual AMD EPYC™ 7003/7002 Series Processors
    (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
  • Socket SP3
Cores
  • Up to 64 Cores
Chipset
  • System on Chip

System Memory
Memory Capacity
  • 16 DIMM slots
  • Supports up to 4TB Registered ECC DDR4 3200MHz SDRAM
  • 8-channel memory bus
  • For Dual CPUs: Recommended that memory be populated equally in adjacent memory banks
Memory Type
  • DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
DIMM Sizes
  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices
SATA
  • SATA3 (6 Gbps)
IPMI
  • Support for Intelligent Platform Management Interface v. 2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2600 BMC
Network Controllers
  • Dual LAN via Broadcom BCM5720L Gigabit Ethernet Controller
VGA
  • ASPEED AST2600 BMC

Input / Output
SATA
  • 10 SATA3 (6 Gbps) ports
LAN
  • 2x 1GbE LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 2.0 ports (rear)
  • 4 USB 3.0 ports (2 rear, 2 headers)
VGA
  • 1 VGA port
Others
  • 1 COM port (rear)
  • 2 SATA DOM power connectors
  • 4 PCI-E 4.0 NVMe x4 internal ports
  • TPM 2.0 header

Expansion Slots
PCI-Express
  • 3 PCI-E 4.0 x16 slots
  • 3 PCI-E 4.0 x8 slots
M.2
  • Interface: 1 PCI-E 4.0 x4
  • Form Factor: 2280, 22110
  • Key: M-key
Chassis ( Optimized for H12DSi-N6)
2U
3U

Server(s) (with H12DSi-N6)
Model(s)

System BIOS
BIOS Type
  • AMI 256Mb SPI Flash EEPROM
BIOS Features
  • Plug and Play (PnP)
  • DMI 2.3
  • PCI 2.2
  • ACPI 6.2
  • USB Keyboard Support
  • SMBIOS 3.1.1

Management
Software
Power Configurations
  • ACPI Power Management
  • Power-on mode control for AC power loss recovery

PC Health Monitoring
CPU
  • Monitors CPU Core Voltages, +1.5V, +1.8V, +12V, +5V, +5V standby
  • CPU switching voltage regulator
  • VBAT
FAN
  • Up to 8 fan status tachometer monitoring
  • Up to 8x 4-pin fan headers
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU Thermal Trip Support
  • Thermal control for 8x Fan connectors
  • I²C Temperature Sensing Logic
LED
  • CPU / System Overheat LED
Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header

Operating Environment / Compliance
Environmental Specifications
  • Operating Temperature:
       10°C to 35°C (50°F to 95°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
Parts List
Bulk Pack List
  Part Number Qty Description
Motherboard MBD-H12DSi-N6-B 1 H12DSi-N6 Motherboard
I/O Shield MCP-260-00042-0N 1 STD I/O SHIELD
I/O Cables CBL-0044L 2 57.5CM SATA FLAT S-S PBF
Retail Pack List
  Part Number Qty Description
Motherboard MBD-H12DSi-N6-O 1 H12DSi-N6 Motherboard
I/O Shield MCP-260-00042-0N 1 STD I/O SHIELD
I/O Cables CBL-0044L 4 57.5CM SATA FLAT S-S PBF
Optional Parts List
  Part Number Qty Description
TPM security module AOM-TPM-9655V - TPM 1.2 module with Infineon 9655, RoHS/REACH,PBF;
AOM-TPM-9665V - TPM 2.0 module with Infineon 9665, RoHS/REACH,PBF;
