MBD-H12SSL-CT-O Supermicro

MBD-H12SSL-CT-O

Key Features

1.Single AMD EPYC™ 7003/7002 Series Processor
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)

2.2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs

3.Expansion slots:
 5 PCI-E 4.0 x16
 2 PCI-E 4.0 x8
 M.2 Interface: 2 PCI-E 4.0 x4
 M.2 Form Factor: 2280, 22110
 M.2 Key: M-key

4.8 SATA3, Broadcom 3008 SAS3 (12 Gbps) controller for 8 SAS3 ports, 2 M.2

5.Dual 10GBase-T LAN via Broadcom BCM57416

6.ASPEED AST2500 BMC graphics

7.Up to 6 USB 3.0 ports
 (4 rear + 2 via header)

8.7 PWM 4-pin Fans with tachometer status monitoring



Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Product SKUs
MBD-H12SSL-CT
  • H12SSL-CT
MBD-H12SSL-CT-O
  • H12SSL-CT (Retail Pack)
Physical Stats
Form Factor
  • ATX
Dimensions
  • 12" x 9.6" (30.5cm x 24.4cm)
Processor/Chipset
CPU
  • Single AMD EPYC™ 7003/7002 Series Processor
    (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
  • Socket SP3
Cores
  • Up to 64 Cores
Chipset
  • System on Chip
System Memory
Memory Capacity
  • 8 DIMM slots
  • Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM
  • 8-channel memory bus
Memory Type
  • DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
DIMM Sizes
  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
On-Board Devices
SATA
  • SATA3 (6 Gbps)
SAS
  • Broadcom 3008 SAS3 (12 Gbps) controller
  • RAID 0, 1, 10
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
Network Controllers
  • Dual 10GBase-T LAN via Broadcom BCM57416
  • 1 Realtek RTL8211F PHY (dedicated IPMI)
VGA
  • ASPEED AST2500 BMC
Input / Output
SATA
  • 8 SATA3 (6 Gbps) ports
SAS
  • 8 SAS3 (12 Gbps) ports
LAN
  • Dual 10GBase-T LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 6 USB 3.0 ports
    (4 rear + 2 via header)
VGA
  • 1 VGA port
Others
  • 1 COM port (rear)
  • 2 SATA DOM power connectors
  • 1 TPM 2.0 header
Expansion Slots
PCI-Express
  • 5 PCI-E 4.0 x16
  • 2 PCI-E 4.0 x8
M.2
  • Interface: 2 PCI-E 4.0 x4
  • Form factor: 2280, 22110
  • Key: M-key
Chassis (Optimized for H12SSL-CT)
1U
2U
3U
Mid-Tower
  • SC732i-903B
Tower/4U
System BIOS
BIOS Type
  • AMI 256Mb SPI Flash EEPROM
BIOS Features
  • Plug and Play (PnP)
  • DMI 2.3
  • PCI 2.2
  • ACPI 5.1
  • USB Keyboard Support
  • SMBIOS 3.1.1
Management
Software
Power Configurations
  • ACPI Power Management
  • Power-on mode control for AC power loss recovery
PC Health Monitoring
CPU
  • Monitors CPU Core Voltages, +3.3V, +5V, +5V standby, +3.3V standby
  • CPU switching voltage regulator
  • Supports system management utility
  • VBAT
FAN
  • Up to 7-fan status tachometer monitoring
  • Up to 7 4-pin fan headers
  • Dual Cooling Zone
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU Thermal Trip Support
  • Thermal control for 7x Fan connectors
  • I²C Temperature Sensing Logic
LED
  • CPU / System Overheat LED
Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header
  • UID
Operating Environment / Compliance
Environmental Specifications
  • Operating Temperature:
    10°C to 35°C (50°F to 95°F)
  • Non-operating Temperature:
    -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
    8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
    5% to 95% (non-condensing)
Parts List
Bulk Pack List
Part Number Qty Description
H12SSL-CT MBD-H12SSL-CT-B 1 H12SSL-CT Motherboard
I/O Cable CBL-0044L 2 57.5CM SATA FLAT S-S PBF
I/O Shield MCP-260-00042-0N 1 STD I/O SHIELD FOR X9 SOCKET R SERVER MB
Retail Pack List
Part Number Qty Description
H12SSL-CT MBD-H12SSL-CT-O 1 H12SSL-CT Motherboard
I/O Cable CBL-0044L 2 57.5CM SATA FLAT S-S PBF
I/O Cable CBL-SAST-0658 2 INT Mini-SAS HD CBL for PCIe SSD NVMe 12Gb/s 60cm 30AWG
I/O Shield MCP-260-00042-0N 1 STD I/O SHIELD FOR X9 SOCKET R SERVER MB
Optional Parts List
Part Number Qty Description
I/O Cable CBL-SAST-0699 - MINI SAS HD-4 SATA,12G,INT,75/75/90/90CM,75CM SB,28/30AWG,Ro
TPM security module AOM-TPM-9655V - TPM 1.2 module with Infineon 9655, RoHS/REACH,PBF;
AOM-TPM-9665V - TPM 2.0 module with Infineon 9665, RoHS/REACH,PBF;
