MBD-H12SSW-NT-O Supermicro

MBD-H12SSW-NT-O

1.Single AMD EPYC™ 7003/7002 Series Processor
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)

2.2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs

3.Expansion slots:
1 PCI-E 4.0 x32 Left Riser Slot
1 PCI-E 4.0 x16 Right Riser Slot
M.2 Interface: 2 SATA/PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-key

4.2 NVMe via SlimSAS,
4 NVMe or 16 SATA3 via SlimSAS,
2 M.2,
2 SATA3

5.2x 10GBase-T LAN Ports via Broadcom BCM57416

6.ASPEED AST2500 BMC graphics

7.Up to 7 USB 3.0 ports

8.6x 4-pin PWM Fans & Speed control



Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Product SKUs
MBD-H12SSW-NT
  • H12SSW-NT (for server SKUs only)

Physical Stats
Form Factor
  • Proprietary WIO
Dimensions
  • 8.15" x 13.05"

Processor/Chipset
CPU
  • Single AMD EPYC™ 7003/7002 Series Processor
    (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
  • Socket SP3
Cores
  • Up to 64 Cores
Chipset
  • System on Chip

System Memory
Memory Capacity
  • 8 DIMM slots
  • Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
  • 8-channel memory bus
Memory Type
  • DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
DIMM Sizes
  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices
SATA
  • SATA3 (6 Gbps)
IPMI
  • Support for Intelligent Platform Management Interface v. 2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
Network Controllers
  • 2x 10GbE LAN Ports via Broadcom BCM57416
  • 1 Realtek RTL8211E PHY (dedicated IPMI)
VGA
  • ASPEED AST2500 BMC

Input / Output
SATA
  • 2 SATA3 (6 Gbps) ports
SATA/NVMe Hybrid
  • 16 SATA3 / 4 NVMe (PCI-E Gen3)
NVMe
  • 2 NVMe (PCI-E Gen4)
LAN
  • 2 RJ45 10GBase-T LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 7 USB 3.0 ports (4 rear, 2 via header, 1 Type A)
VGA
  • 1 VGA port
Others
  • 1 COM port
  • 2 SuperDOM power connectors
  • 1 TPM 1.2/2.0 header

Expansion Slots
PCI-Express
  • 1 PCI-E 4.0 x32 Left Riser Slot
  • 1 PCI-E 4.0 x16 Right Riser Slot
M.2
  • Interface: 2 SATA/PCI-E 3.0 x2
  • Form Factor: 2280, 22110
  • Key: M-key
Chassis (Optimized for H12SSW-NT)
1U
2U

Server(s) (with H12SSW-NT)
Model(s)

System BIOS
BIOS Type
  • AMI 256Mb SPI Flash EEPROM
BIOS Features
  • Plug and Play (PnP)
  • DMI 2.3
  • PCI 2.2
  • ACPI 5.1
  • USB Keyboard Support
  • SMBIOS 3.1.1

Management
Software
Power Configurations
  • ACPI Power Management
  • Power-on mode control for AC power loss recovery

PC Health Monitoring
CPU
  • Monitors CPU Core Voltages, +1.5V, +1.8V, +12V, +5V, +5V standby
  • CPU switching voltage regulator
FAN
  • Up to 6 fan status tachometer monitoring
  • Up to 6 4-pin fan headers
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU Thermal Trip Support
  • Thermal control for 6x Fan connectors
  • I²C Temperature Sensing Logic
LED
  • CPU / System Overheat LED
Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header

Operating Environment / Compliance
Environmental Specifications
  • Operating Temperature:
       10°C to 35°C (50°F to 95°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
Parts List
Retail Pack List
  Part Number Qty Description
H12SSW-NT MBD-H12SSW-NT -O 1 H12SSW-NT Motherboard
Optional Parts List
  Part Number Qty Description
TPM security module AOM-TPM-9655V - TPM 1.2 module with Infineon 9655, RoHS/REACH,PBF;
AOM-TPM-9665V - TPM 2.0 module with Infineon 9665, RoHS/REACH,PBF;
