MBD-X12SDV-16C-SPT8F-O Supermicro
  • MBD-X12SDV-16C-SPT8F-O Supermicro

MBD-X12SDV-16C-SPT8F-O Supermicro

MBD-X12SDV-16C-SPT8F-O
  1. System on Chip
  2. Intel® Xeon® Processor D-2775TE, CPU TDP 100W
  3. Up to 256GB Registered ECC RDIMM, DDR4-3200MHz; Up to 512GB LRDIMM LRDIMM, DDR4-3200MHz, in 4 DIMM slots
  4. 1 PCI-E 4.0 x16
  5. 2 PCI-E 4.0 NVMe x8 SlimSAS Internal Port
  6. 1 OCuLink Connector (4 SATA/PCI-E 3.0 x4)
    1 M.2 M-Key 2242/2280 (SATA/PCI-E 3.0 x4)
  7. Quad 1G RJ45 with Intel® I350-AM4
    Dual 25G SFP28 with Intel SoC
    Dual 10Gbase-T RJ-45 with Intel® Ethernet Controller X550-AT2
  8. SoC controller for 2 SATA3 (6 Gbps) ports; RAID 0,1
  9. 12V DC or ATX Power Input


Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Product SKUs
MBD-X12SDV-16C-SPT8F
  • X12SDV-16C-SPT8F

Physical Stats
Form Factor
  • Micro-ATX
Dimension
  • 7.5" x 8.5" (19.05cm x 21.59cm)

Processor
CPU
  • Intel® Xeon® Processor D-2775TE
  • Single Socket FCBGA-2579 supported, CPU TDP supports Up to 100W TDP
Core
  • Up to 16 cores / 25MB Cache

System Memory
Memory Capacity
  • 4 DIMM slots
  • Up to 512GB ECC LRDIMM, DDR4-3200MHz; Up to 256GB ECC RDIMM, DDR4-3200MHz; Up to 512GB ECC/non-ECC , DDR4-3200MHz
Memory Type
  • 3200/2933/2666/2400MHz ECC/non-ECC DDR4 LRDIMM, RDIMM
DIMM Sizes
  • LRDIMM: 64GB, 128GB
  • RDIMM: 8GB, 16GB, 32GB, 64GB
  • UDIMM: 4GB, 8GB, 16GB, 32GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices
Chipset
  • System on Chip
SATA
  • SoC controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • 4 SATA ports via OCuLink (or PCIE3.0 x4 for NVMe)
IPMI
  • ASPEED AST2600 BMC
Graphics
  • Aspeed AST2600 BMC
Network Controllers
  • Dual LAN with 25G SFP28 LAN via SoC
  • Dual LAN with Intel® X550 10GBase-T Ethernet Controller
  • Quad LAN with Intel® i350 Gigabit Ethernet Controller

Input / Output
SATA
  • 2 SATA3 (6Gbps) port(s)
LAN
  • 4 RJ45 Gigabit Ethernet LAN ports
  • 2 SFP28 25 Gigabit Ethernet LAN ports
  • 2 RJ45 10GBase-T ports
USB
  • 4 USB 2 port(s) (4 via header)
  • 2 USB 3 port(s) (2 rear type A)
Video Output
  • 1 VGA D-Sub Connector port(s)
Serial Port
  • 1 COM Port(s) (1 header)
DOM
  • 1 SATA DOM (Disk on Module) power connector support
TPM
  • 1 TPM Header & Chip both
Expansion Slots
PCI-E
  • 1 PCI-E 4.0 x16,
  • 1 PCI-E 3.0 x4 (or 4x SATA), via Oculink,
  • 2 PCI-E 4.0 x8, via SlimSAS
M.2
  • M.2 Interface: 1 SATA/PCI-E 3.0 x4
  • Form Factor: 2242/2280
  • Key: M-Key

System BIOS
BIOS Type
  • AMI 32MB SPI Flash EEPROM
BIOS Features
  • ACPI 6.3
  • UEFI 2.7
  • SMBIOS 3.3
  • Plug and Play (PnP)
  • PCI FW 3.0

Management
Software
  • Watchdog, IPMI (Intelligent Platform Management Interface) v2.0 with KVM support, SuperDoctor® 5, SSM, NMI, SUM, SPM
Power Configurations
  • ATX Power connector, +12V DC Power Input, CPU thermal trip support for processor protection, Power-on mode for AC power recovery

PC Health Monitoring
Voltage
  • 3.3V standby, +5V standby, +5V, +3.3V, +12V, Memory Voltages, Monitors CPU Core Voltages
LED
  • UID/Remote UID
  • BMC/IPMI Heartbeat LED
  • Overheat/Fan Fail/PWR Fail LED
  • Power Indicator LED
  • LAN temperature
Temperature
  • CPU thermal trip support
  • peripheral temperature
  • System temperature
  • Memory temperature
  • NVMe temperature
  • Platform Environment Control Interface (PECI)/TSI
FAN
  • 6x 4-pin fan headers (up to 6 fans)
  • System level control, PWM fan speed control, Fan speed control, 6 fans with tachometer status monitoring, Overheat LED indication, Dual Cooling Zones
Other Features
  • UID, RoHS, Node Manager Support, Chassis intrusion header, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, 12V DC or ATX Power Source

Operating Environment
Operating Temperature Range
  • 0°C - 60°C (32°F - 140°F)
Non-Operating Temperature Range
  • -40°C - 85°C (-40°F - 185°F)
Operating Relative Humidity Range
  • 10% - 85% (non-condensing)
Non Operating Relative Humidity Range
  • 10% - 95% (non-condensing)
Détails du produit
MBD-X12SDV-16C-SPT8F-O
MBD-X12SDV-16C-SPT8F-O
Produit en fin de vie

Fiche technique

Référence produit
X12SDV-16C-SPT8F
Format
Micro-ATX
Processeur
ntel® Xeon® Processor D-2775TE
Mémoires
Up to 512GB ECC LRDIMM, DDR4-3200MHz
Chipset Réseaux
Dual LAN with 25G SFP28 LAN via SoC
Dual LAN with Intel® X550 10GBase-T Ethernet Controller
Quad LAN with Intel® i350 Gigabit Ethernet Controller
