RS700A-E11-RS12U Asus

RS700A-E11-RS12U

ASUS RS700A-E11-RS12U AMD EPYC 7003 1U dual-socket server

AMD EPYC™ 7003 2U dual-socket server that supports up to 32 DIMM, one dual-slot GPU, 12 NVMe, 3 PCIe 4.0 slots, OCP 3.0, M.2 and ASMB10-iKVM



Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
  • Processor / System Bus
    2 x Socket SP3 (LGA 4094)
    AMD EPYC™ 7003 Series
    AMD EPYC™ 7002 Series
    Max TDP : 280W
  • Generation
    E11
  • Memory
    Total Slots :
    32 (8-channel per CPU, 16 DIMM per CPU)
    Capacity :
    Maximum up to 4096GB RDIMM
    Memory Type :
    Dual Channel DDR4 3200/2933 RDIMM
    Dual Channel DDR4 3200/2933 LRDIMM
    Dual Channel DDR4 3200/2933 LR-DIMM 3DS non ECC
    Memory Size :
    64GB, 32GB, 16GB RDIMM
    128GB, 64GB LRDIMM
    256GB, 128GB, 64GB LR-DIMM 3DS
    * Refer to support page for more information
  • Graphic Card
    Please refer to GPU support list
  • Expansion Slots
    Up to 3 x Expansion slots + 1 x Internal PIKE slot
    1 x PCIe Gen4 x16, FHFL (CPU1)
    1 x PCIe Gen4 x16, FHFL or OCP3.0 (CPU2)
    1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2)

    *Installing GPU cards will occupied expansion slots.
  • Storage
    Storage Controller :
    12 x SATA3 6Gb/s ports (SATA 6Gb/s & PCIe® Gen4 x4 link)
    2 x M.2 connector(2242/2260/2280/22110) both SATA & PCIe mode
    SAS Controller :
    ASUS PIKE II 3008-8i 8-port SAS 12G RAID card(Optional)
    ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card(Optional)
    Broadcom MegaRAID 9560-16i (Optional)
  • Drive Bays
    12 x 2.5" hot-swap drive bays (12 x NVMe/SATA/SAS*)
    2 x M.2 (support SATA/PCIe M.2) (up to 22110) (CPU2)

    *must with PIKE/RAID card
  • System Fan
    8
  • Networking
    Option 1
    1 x Quad Port Intel I350-AM4 1G LAN Controller + 1 x Mgmt LAN
    or
    Option 2
    1 x Dual Port Intel X710-AT2 Gigabit 10G LAN Controller + 1 x Mgmt LAN
    or
    None
  • Graphic
    Aspeed AST2600 with 64MB VRAM
  • Rear I/O Ports
    2 x USB 3.2 Gen1 ports
    1 x VGA port
    1 x RJ-45 Mgmt LAN port
    1 x OCP3.0 port (Please remember to insert OCP3.0 Board)
  • Switch/LED
    Front Switch/LED:
    1 x Power switch (w/LED)
    1 x Reset Switch
    1 x Location Switch (w/LED)
    1 x HDD Access LED
    1 x Message LED LAN 1-4 LED (on NIC Module)

    Rear Switch/LED:
    1 x Power switch w/LED
    1 x Port 80 LED(Q-Code)
    1 x Location Switch w/LED
    1 x Message LED
  • OS Support
    Please find the latest OS support from https://www.asus.com/event/Server/OS_support_list/OS.html
  • Management Solution
    On-Board ASMB10-iKVM for KVM-over-IP
    ASUS Control Center Enterprise (Optional)
  • Regulatory Compliance
    BSMI, CE, FCC(Class A)
  • Dimensions
    842.5mm x 449mm x 43.85mm (33.17" x 17.68" x 1.73")
  • Form Factor
    1U
  • Weight
    Net Weight : 18.85KG
    Gross Weight : 23.89KG
  • Power Supply
    1+1 Redundant 1200W/1600W 80 PLUS Platinum Power Supply
    Rating: 100-127/200-240Vac,9.4A/4.72A (x2) ,50/60Hz Class I (240Vdc, 4.6A Only for China)

    *1600W RPSU is required while choosing GPU SKU
  • Environment
    Operation temperature: 10℃ ~ 35℃
    Non operation temperature: -40℃ ~ 60℃
    Non operation humidity: 20% ~ 90% (Non condensing)
  • Optional Items
    Standard Cooling Solution or
    Water Cooling Solution
  • Note
    *If only 1 CPU is installed, some functions might be not available.
    * SAS support only from SAS HBA/RAID Card

Part List

  • CPU Heatsink/ Cooler
    2
  • Fan
    1 (For supporting GPU SKU, it will have external fan)
Détails du produit
RS700A-E11-RS12U
RS700A-E11-RS12U

Fiche technique

Référence produit
RS700A-E11-RS12U
Format
1U
Processeur
AMD EPYC™ 7003 Series
Mémoires
32 (8-channel per CPU, 16 DIMM per CPU)
Slot d'expansion PCI-e
1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2)
1 x PCIe Gen4 x16, FHFL (CPU1)
1 x PCIe Gen4 x16, FHFL or OCP3.0 (CPU2)
