Tempest HX S5642
Standard 1S Xeon SP Server Board
- 12" x 10.6" SSI CEB FF
- 8 DIMM slots w/ DDR4-3200 memory support
- 3 PCIe Gen.4 x16 + 2 PCIe Gen.4 x8 slots
- 1 PCIe x8 SlimSAS connector (NVMe)
- 2 NVMe 22110 / 2280 M.2 slots
- 2 10GBase-T LAN + 1 1000Base-T + 1 dedicate 1000Base-T IPMI ports
- AST2500 BMC with IPMI 2.0 & Redfish support
S5642AGM3NRE-2T Tyan
Tempest HX S5642
Standard 1S Xeon SP Server Board
- 12" x 10.6" SSI CEB FF
- 8 DIMM slots w/ DDR4-3200 memory support
- 3 PCIe Gen.4 x16 + 2 PCIe Gen.4 x8 slots
- 1 PCIe x8 SlimSAS connector (NVMe)
- 2 NVMe 22110 / 2280 M.2 slots
- 2 10GBase-T LAN + 1 1000Base-T + 1 dedicate 1000Base-T IPMI ports
- AST2500 BMC with IPMI 2.0 & Redfish support
| Processor | Q'ty / Socket Type | (1) LGA4189 |
| Supported CPU Series | 3rd Gen Intel Xeon Scalable Processor | |
| Thermal Design Power Wattage | Max up to 270W (TDP) | |
| System Bus | Up to 11.2/10.4 GT/s with Intel UltraPath Interconnect (UPI) support | |
| Chipset | PCH | Intel C621A |
| Memory | Supported DIMM Qty | (8) DIMM slots |
| DIMM Type / Speed | DDR4 ECC RDIMM /LRDIMM 3200 | |
| Capacity | Up to 1,024GB RDIMM/ 2,048GB LRDIMM/ 2,048GB RDIMM 3DS/LRDIMM 3DS *Follow latest Intel DDR4 Memory POR | |
| Memory channel | 8 Channels per CPU | |
| Memory voltage | 1.2V | |
| Expansion Slots | PCIe | (1) PCIe Gen.4 x8 slot (#4 w/x4 link) / (1) PCe Gen.4 x8 slot (#2 via MUX) / (1) PCIe Gen.4 x16 slot (#3 w/x8 link) / (2) PCIe Gen.4 x16 slots (#5,#6) |
| LAN | Q'ty / Port | (2) 10GbE ports + (1) GbE ports + (1) GbE dedicated for IPMI |
| Controller | Intel I210 / Intel X550-AT2 | |
| PHY | Realtek RTL8211E | |
| Storage SATA | Connector | (2) Mini-SAS HD (8 ports) |
| Controller | Intel C621A | |
| Speed | 6Gb/s | |
| RAID | RAID 0/1/10/5 (Intel RSTe) | |
| Storage sSATA | Connector | (1) Mini-SAS HD (4-ports) / (2) 7-pin SATA for (2) SATA ports |
| Controller | Intel C621A | |
| Speed | 6Gb/s | |
| RAID | RAID 0/1/10/5 (Intel RSTe) | |
| Storage NVMe | Connector (M.2) | (2) 22110/2280 (by PCIe Gen.3 interface) |
| Connector (U.2) | (1) SFF-8654 for (2) NVMe ports | |
| Storage (Optional) | VROC Support | Yes |
| Graphic VGA | Connector type | D-Sub 15-pin |
| Resolution | Up to 1920x1200 | |
| Chipset | Aspeed AST2500 | |
| Input /Output | USB | (2) USB2.0 ports (@ rear) / (2) USB3.0 ports ( @ rear) / (2) USB3.0 ports (via cable) |
| COM | (1) DB-9 COM Connector | |
| VGA | (1) D-Sub 15-pin VGA port (@ rear) | |
| RJ-45 | (2) 10GbE ports + (1) GbE ports + (1) GbE dedicated for IPMI | |
| Front Panel | (1) 2x12-pin SSI front panel header | |
| Audio | (1) 2x5-pin header / (1) 3 holes Audio Jack connector | |
| SATA | (14) SATA-III ports | |
| Power | 8-pin power connectors | |
| Others | (1) UID button | |
| TPM (Optional) | TPM Support | Please refer to our TPM supported list. |
| System Monitoring | Chipset | Aspeed AST2500 |
| Fan | Total (5) 4-pin headers | |
| Temperature | Monitors temperature for CPU, memory & system environment | |
| Voltage | Monitors voltage for CPU, memory, chipset & power supply | |
| LED | Over temperature warning indicator / Fan & PSU fail LED indicator | |
| Others | Watchdog timer support | |
| Audio | Chipset | Realtek ALC888S |
| Feature | 2.1 ch | |
| Server Management | Onboard Chipset | Onboard Aspeed AST2500 |
| AST2500 iKVM Feature | 24-bit high quality video compression / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub | |
| AST2500 IPMI Feature | IPMI 2.0 compliant baseboard management controller (BMC) / 10/100/1000 Mb/s MAC interface | |
| BIOS | Brand / ROM size | AMI / 32MB |
| Feature | Hardware Monitor / Boot from USB device/PXE via LAN/Storage / Console Redirection / User Configurable FAN PWM Duty Cycle / SMBIOS 3.3/PnP/Wake on LAN / ACPI 6.2 / ACPI sleeping states S5 | |
| Physical Dimension | Form Factor | SSI CEB compatible |
| Board Dimension | 12” x 10.5” (305 x 267mm) | |
| Regulation | FCC (SDoC) | Class B |
| CE (DoC) | Class B | |
| RCM | Class B | |
| VCCI | Class B | |
| Operating Environment | Operating Temp. | 0° C ~ 40° C (32° F~ 104° F) |
| Non-operating Temp. | - 40° C ~ 70° C (-40° F ~ 158° F) | |
| In/Non-operating Humidity | 90%, non-condensing at 35° C | |
| RoHS | RoHS 6/6 Compliant | Yes |
| Operating System | OS supported list | Please refer to our AVL support lists. |
| Package Contains | Motherboard | (1) S5642 Motherboard |
| Manual | (1) Quick Installation Guide | |
| I/O Shield | (1) I/O Shield | |
| Cable SATA | (2) SATA signal cables |
S5642AGM3NRE-2T
Fiche technique
- Référence produit
- S5642AGM3NRE-2T
- Format
- 12" x 10.6" SSI CEB FF
- Processeur
- 3rd Gen Intel Xeon Scalable Processor
- Mémoires
- (8) DIMM slots
