SSG-1029P-NEL32R Supermicro

SSG-1029P-NEL32R

Supermicro Serveur SSG-1029P-NEL32R

- High Throughput Ingest
  - High Density Hot Storage
  - HPC / Data Analytics
  - Media/Video Streaming
  - Content Delivery Network (CDN)
  - Big Data Top of Rack Storage



Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Product SKUs
SSG-1029P-NEL32R
  • SuperStorage 1029P-NEL32R (Black)

Motherboard

Super X11DPS-RE

Processor
CPU
  • Dual Socket P (LGA 3647)
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡,
    3 UPI up to 10.4GT/s
  • Support CPU TDP up to 165W
Cores
  • Up to 28 Cores
Note ‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R)

System Memory
Memory Capacity
  • 24 DIMM slots
  • Up to 6TB 3DS ECC DDR4-2933MHz† RDIMM
  • Supports Intel® Optane™ DCPMM††
Memory Type
  • 2933†/2666/2400/2133MHz ECC DDR4 RDIMM
Note † 2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro
†† Cascade Lake only. Contact your Supermicro sales rep for more info.

On-Board Devices
Chipset
  • Intel® C627 chipset
Network Connectivity
  • Intel® X550 Dual Port 10GBase-T
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics
  • ASPEED AST2500 BMC

Input / Output
LAN
  • 2 RJ45 10GBase-T ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 3.0 ports (rear)
Video
  • 1 VGA port
Serial Header
  • 1 COM port (header)

System BIOS
BIOS Type
  • AMI 32Mb SPI Flash ROM

Management
Software
Power Configurations
  • ACPI / APM Power Management

PC Health Monitoring
CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory.
  • 4+1 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor
  • 1U Rackmount
  • 32 EDSFF Long 9.5mm drive slots
Model
  • CSE-136HTS-R1K69P-E2

Dimensions and Weight
Height
  • 1.7" (43mm)
Width
  • 17.26" (438mm)
Depth
  • 35.95" (913mm)
Weight
  • Net Weight: 55 lbs (24.95kg)
  • Gross Weight: 90 lbs (40.82kg)

Front Panel
Buttons
  • Power On/Off button
  • UID button
LEDs
  • Power LED
  • Hard drive activity LED
  • Network activity LEDs
  • System Overheat LED / Fan fail LED /
    UID LED

Expansion Slots
PCI-Express
  • 2 PCI-E 3.0 x16 Low-profile slots
M.2
  • M.2 Interface: 2 PCI-E 3.0 x2
  • M.2 Form Factor: 2260/2280/22110
  • M.2 Key: M-Key
  • *2 SATA Hybrid ports, RAID 0, 1

Drive Bays
Hot-swap
  • 32 Hot-swap EDSFF Long 9.5mm Drive slots

System Cooling
Fans
  • 8x 40x56mm PWM fans

AC/DC240V Input Redundant Power Supply
1000 / 1600W 1U Redundant Power Supply
Total Output Power
  • 1000W: 100 – 127Vac
  • 1600W: 200 – 240Vac
  • 1600W: 200 – 240Vdc (for CCC only)
Dimension
(W x H x L)
  • 73.5 x 40 x 185 mm
Input
  • 100 -- 127Vac / 13.8A / 47-63Hz
  • 200 -- 240Vac / 9.6A / 47-63Hz
  • 200 -- 240Vdc / 8.5A (CCC Only)
+12V
  • Max: 83A / Min: 0A (1000W)
  • Max: 132A / Min: 0A (1600W)
12Vsb
  • Max: 2.1A / Min: 0A
Output Type
  • Gold Finger
Certification Platinum Level Certified  Platinum Certified


Operating Environment
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature:
       -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
