SSG-110P-NTR10 Supermicro

SSG-110P-NTR10

Key Applications- Virtualization
- Cloud Computing
- All Flash Storage
- CDN Optimized


Key Features

  1. Single Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors. Up to 270W TDP.
  2. 8 DIMMs; Supports 3DS DDR4-3200: RDIMM/LRDIMM/Intel® DCPMM
  3. 1 PCI-E 4.0 x16 (FHHL) slot
  4. Intel® Ethernet Controller X550 2x 10GbE RJ45
  5. 10x Hot-swap 2.5'' All NVMe Gen 4 tool-less drive bays; Onboard 2x NVMe Gen 3/SATA M.2
  6. Redundant Platinum 860W Power Supply


Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Product SKUs
SSG-110P-NTR10
  • SuperServer SSG-110P-NTR10 (Black)

Motherboard


Super X12SPO-NTF

Processor
CPU
  • Single Socket P+ (LGA 4189)
  • Support Intel® 3rd Gen Xeon® Scalable Processors
  • Support CPU TDP 270W

System Memory
Memory
  • Memory Capacity: 8 DIMM slots
  • Up to 2TB: 8x 256 GB DRAM
  • Up to 3TB: 4x 256 GB DRAM and 4x 512 GB PMem
  • Memory Type: 3200/2933/2666MHz ECC DDR4 RDIMM;LRDIMM
  • Intel® Optane™ persistent memory 200 series
Memory Voltage
  • 1.25 V
Error Detection
  • Yes

On-Board Devices
NVMe
  • NVMe Gen 4 via MB onboard controller; RAID 0, 1, 5, 10 support (with additional VROC module)
Chipset
  • Intel® C621A
Network Connectivity
  • 2x 10GbE BaseT with Intel® X550
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Input / Output
LAN
  • 1 RJ45 Dedicated IPMI LAN port
  • 2 RJ45 10GBase-T LAN ports
USB
  • 5 USB 3.2 Gen 1 port(s) (2 front; 2 rear; 1 Type A)
  • 4 USB 2.0 port(s) (2 headers; 2 rear)
Video
  • 1 VGA port(s)
Serial Port
  • 2 COM Port(s) (1 header; 1 rear)
DOM
  • 2 SuperDOM (Disk on Module) port with built-in power

System BIOS
BIOS Type
  • AMI 32MB SPI Flash EEPROM

Management
Software
  • IPMI2.0
  • Redfish API
  • SSM
  • Intel® Node Manager
  • SPM
  • KVM with dedicated LAN
  • SUM
  • NMI
Power Configurations
  • ACPI/APM Power Management

PC Health Monitoring
CPU
  • 7+1 Phase-switching voltage regulator module (VRM)
  • Monitors for CPU Cores, Chipset Voltages, Memory
FAN
  • Fans with tachometer monitoring
  • Pulse Width Modulated (PWM) fan connectors
  • Status monitor for speed control
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor
  • 1U Rackmount
Model
  • CSE-116TS-R860CBP-N10

Dimensions and Weight
Height
  • 1.7" (43mm)
Width
  • 17.2" (437mm)
Depth
  • 23.5" (597mm)
Package
  • 8" (H) x 24" (W) x 32" (D)
Weight
  • Net Weight: 25 lbs (11.34 kg)
  • Gross Weight: 38 lbs (17.24 kg)
Available Color
  • Black

Front Panel
Buttons
  • Power On/Off
  • UID button
LEDs
  • Device Activity
  • LAN 1 Activity
  • LAN 2 Activity
  • Power status
  • System information

Expansion Slots
PCI-Express (PCI-E)
  • Slot 1: PCI-E 4.0 x16 FHHL

Drive Bays / Storage
Hot-swap
  • 10x 2.5" hot-swap NVMe drive bays (10x 2.5" NVMe dedicated)
M.2
  • 2x PCI-E 3.0 x4 and SATA
  • Form Factor: 2280, 22110
  • Key: M-key

System Cooling
Fans
  • 6x (4cm x4cm x5.6cm) heavy duty fans with optimal fan speed control
Air Shroud
  • 1 Air Shroud(s)

Power Supply
AC 860W, Platinum Level, Redundant Power Supply, 54.5mm width
Dimension

(W x H x L)
  • 54.5 x 40.25 x 320 mm
Output Type
  • Gold Finger
Certification Platinum Level Certified94%+  Platinum Level




  Test Report ]

Operating Environment
Environmental Spec.
  • Operating Temperature:
       10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
