Supermicro SuperServer SYS-E200-9A

1. Intel® Atom® processor C3558,
    Single socket FCBGA 1310

2. System on Chip

3. 1 fixed 2.5" SSD bay with bracket
    (7mm drive recommended;
    9.5mm drive can be used with Low-
    Profile Memory)

4. Up to 256GB ECC RDIMM DDR4
    2400MHz or 64GB ECC/non-ECC
    UDIMM in 4 sockets

5. M.2 PCI-E 3.0 x2 and SATA,
    M Key 2242/2280

6. 4 GbE LAN ports with C3000 SoC,
    dedicated LAN for IPMI 2.0

7. VGA via BMC, 2 USB 2.0 ports

8. 2x 40mm chassis fans

9. 60W lockable power adapter

Product SKUs
SYS-E200-9A
  • SuperServer E200-9A (Black)

Motherboard

Super A2SDi-4C-HLN4F

Processor/Cache
CPU
  • Intel® Atom® processor C3558
  • FCBGA 1310
  • CPU TDP support 16W

System Memory
Memory Capacity
  • 4x DDR4 DIMM sockets
  • Supports up to 256GB DDR4 ECC RDIMM
  • Supports up to 64GB DDR4 ECC/non-ECC UDIMM
Memory Type
  • 2400/2133/1866MHz ECC DDR4 ECC RDIMM and ECC/Non-ECC UDIMM
DIMM Sizes
  • 32GB, 16GB, 8GB, 4GB
Memory Voltage
  • 1.2 V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors
      (using ECC memory)

On-Board Devices
Chipset
  • System on Chip
SATA
  • SoC controller for 8 SATA3 (6Gbps) ports
Network Controllers
  • Quad Gigabit Ethernet LAN via Intel® C3000 SoC
  • Supports 10GBASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
  • 1 Realtek RTL8201N PHY (dedicated IPMI)
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics
  • Aspeed AST2400

Input / Output
SATA
  • 1 SATA3 (6Gbps) port
LAN
  • 4 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 2.0 ports (rear)
Display
  • 1 VGA port
DOM
  • 1 SuperDOM (Disk on Module) power connector
TPM
  • TPM 2.0 header
Chassis
Form Factor
  • Mini-1U
Model

Dimensions
Width
  • 7.6" (193mm) / 15" (381mm) - pkg.
Height
  • 1.7" (43mm) / 10.87" (276mm) - pkg.
Depth
  • 8.9" (226mm) / 5.59" (142mm) - pkg.
Weight
  • Gross Weight: 6.5 lbs (2.95 kg)
  • Net Weight: 3.0 lbs (1.36 kg)
Available Colors
  • Black

Front Panel
Buttons
  • Power On/Off button
LEDs
  • Power LED (Hard drive activity LED)

Expansion Slots
M.2
  • Interface: PCI-E 3.0 x2 or SATA3
  • Form Factor: M Key 2242/2280

Drive Bays
Internal
  • 1 fixed 2.5" SSD bay with bracket (7mm drive recommended; 9.5mm drive can be used with Low-Profile memory)

System Cooling
Fans
  • 2x 40mm chassis fans

Power Supply
60W lockable power adapter

System BIOS
BIOS Type
  • 128Mb SPI Flash with AMI BIOS
BIOS Features
  • PCI 3.0
  • ACPI 5.0
  • USB Keyboard support
  • Hardware BIOS Virus protection
  • SMBIOS 2.8
  • UEFI 2.4
  • RTC (Real Time Clock) Wakeup

Management
Software
Power Configurations
  • ACPI / APM Power Management
  • CPU Fan auto-off in sleep mode
  • Power-on mode for AC power recovery
Fan
  • Fans with tachometer status monitoring
  • Status monitor for speed control
  • Low noise fan speed control
  • Pulse Width Modulated (PWM) fan connectors

Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       0°C to 40°C (32°F to 104°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
