SYS-E300-9A-8CN8 Supermicro

SYS-E300-9A-8CN8

Supermicro Serveur SYS-E300-9A-8CN8 Embedded/IoT E300-9A-8CN8

Key Features  - Virtual-CPE White Box Solution
  - Network Security Appliance
  - Embedded IoT Gateway
  - Networking Edge Device

1. Intel® Atom® processor C3758,
    Single socket FCBGA 1310

2. System on Chip

3. 1 fixed 2.5" drive bay
    when AOC area is not occupied

4. Up to 256GB registered ECC,
    up to 64GB unbuf. ECC/non-ECC,
    DDR4-2400MHz, in 4 DIMM slots

5. 1 PCI-E 3.0 x4 AOC slot (LP)

6. 4 GbE LAN ports w/ Intel i350-AM4
    4 GbE LAN ports w/ Marvell 88E1543

7. 2 USB 3.0, 1 M.2 B Key 3042.2280,
    1 M.2 M Key 2242/2280

8. 1 VGA via BMC

9. 1x 40mm chassis fan, passive
    CPU heat sink

10. 84W DC power adapter



Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Product SKUs
SYS-E300-9A-8CN8
  • SuperServer E300-9A-8CN8 (Black)

Motherboard

Super A2SDV-8C-LN8F

Processor/Cache
CPU
  • Intel® Atom® processor C3758
  • 8 Cores, 2.2GHz
  • CPU TDP support 25W
  • FCBGA 1310

System Memory
Memory Capacity
  • 4x DDR4 DIMM sockets
  • Supports up to 256GB DDR4 ECC RDIMM
  • Supports up to 64GB DDR4 ECC/non-ECC UDIMM
Memory Type
  • 2400/2133/1866MHz ECC DDR4 ECC RDIMM and ECC/Non-ECC UDIMM
DIMM Sizes
  • 64GB, 32GB, 16GB, 8GB, 4GB
Memory Voltage
  • 1.2 V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors
      (using ECC memory)

On-Board Devices
Chipset
  • System on Chip
SATA
  • SoC controller for 4 SATA3 (6Gbps) ports
Network Controllers
  • Quad LAN with Intel® C3000 SoC
  • Quad LAN with Intel® Ethernet Controller I350-AM4
Graphics
  • Aspeed AST2400

Input / Output
SATA
  • 2 SATA3 (6Gbps) ports
LAN
  • 8 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 3.0 ports (rear)
Display
  • 1 VGA port
DOM
  • 1 SuperDOM (Disk on Module) power connector
TPM
  • TPM 2.0 header
Chassis
Form Factor
  • Mini-1U
Model
  • CSE-E300-LED

Dimensions
Width
  • 10" (254mm) / 15" (381mm) - pkg.
Height
  • 1.7" (43mm) / 10.87" (276mm) - pkg.
Depth
  • 8.9" (226mm) / 5.59" (142mm) - pkg.
Weight
  • Gross Weight: 7.5 lbs (3.4 kg)
  • Net Weight: 3.45 lbs (1.56 kg)
Available Colors
  • Black

Front Panel
Buttons
  • Power On/Off button
LEDs
  • Power LED (Hard drive activity LED)

Expansion Slots
PCI-Express
  • 1 PCI-E 3.0 x4 AOC slot (LP)

Drive Bays / Storage
Internal
  • 1 fixed 2.5" drive bay when AOC area is not occupied
M.2
  • 2 M.2 Key
  • Interface: PCI-E 3.0 x2
  • Form Factor: B Key 3042/2280
  • Form Factor: M Key 2242/2280

System Cooling
Fans
  • 1x 40mm chassis fan

Power Supply
84W DC power adapter

System BIOS
BIOS Type
  • AMI UEFI
BIOS Features
  • UEFI 2.4
  • SMBIOS 2.7.1

Management
Software
Power Configurations
  • ACPI / APM Power Management
  • CPU thermal trip support for processor protection
  • Power-on mode for AC power recovery

Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       0°C to 40°C (32°F to 104°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
Parts List
Parts List - (Items Included)
  Part Number Qty Description
Motherboard / Chassis MBD-A2SDV-8C-LN8F
CSE-E300-LED
1
1
Super A2SDV-8C-LN8F Motherboard
Embedded Server BOX for Mini-ITX 1U w/o PWS
Cooling Fan FAN-0065L4 - 40x28mm 13K RPM 4-PIN PWM FAN
Power Adapter MCP-250-10137-0N 1 84W DC Power Adapter
Optional Parts List
  Part Number Qty Description
Chassis Parts MCP-290-30002-0B - CSE-E300 Rackmount kit (150W/180W adapter supported)
Cable CBL-CUSB-0975 - RJ45 SERIAL Cable for Console
