SYS-E300-9D-4CN8TP Supermicro

Référence SYS-E300-9D-4CN8TP

Marque Supermicro

Supermicro Serveur SYS-E300-9D-4CN8TP Embedded/IoT E300-9D-4CN8TP

Key Features - Network Security Appliance
- SDN-WAN, vCPE controller box
- NFV Edge Computing Server
- Virtualization Server
- IoT Edge Computing/Gateway

1. Intel® Xeon® processor D-2123IT,
4-Core, 8 Threads, 60W

2. System on Chip

3. 1 Fixed 2.5" drive bay with bracket

4. 1 M.2 slot M key for SSD, 2242/8,
    1 M.2 B Key for SSD/ WAN card,
    1 Mini-PCI-E with mSATA Support,
    1 PCI-E 3.0 x8 slot

5. Up to 512GB ECC LRDIMM,
up to 256GB ECC DIMM
DDR4-2666Mz; in 4 DIMM slots

6. 4x 1GbE, 2x 10GBase-T, 2x 10G SFP+
and 1 dedicated LAN for IPMI 2.0

7. 1 VGA, 2 USB 3.0

8. 3x 40x28mm 4-PIN PWM Fan

9. Low-noise DC Power Supply

Garanties sécurité (à modifier dans le module "Réassurance")

Politique de livraison (à modifier dans le module "Réassurance")

Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com

Description
Détails du produit

Description

Product SKUs

SYS-E300-9D-4CN8TP	SuperServer E300-9D-4CN8TP (Black)


Motherboard

Super X11SDV-4C-TP8F


Processor/Cache

CPU	Intel® Xeon® processor D-2123IT, CPU TDP support 60W
Cores / Cache	4 Cores, 8 Threads


System Memory

Memory Capacity	Up to 512GB DDR4 ECC LRDIMM Up to 256GB DDR4 ECC DIMM 4 DIMM slots
Memory Type	2666/2400/2133MHz ECC LRDIMM and ECC DIMM Operating speed up to 2400MHz
DIMM Sizes	RDIMM: 4GB, 8GB, 16GB, 32GB, 64GB LRDIMM: 16GB, 32GB, 64GB, 128GB
Memory Voltage	1.2 V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)


On-Board Devices

Chipset	System on Chip
SATA	SATA3 (6Gbps) ports via SoC controller
Network Controllers	Quad 1GbE with Intel I350-AM4 Dual 10GBase-T with Intel X557 Dual 10G SFP+ via SoC
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics	Aspeed AST2500 BMC


Input / Output

SATA	SoC controller for 4 SATA3 (6Gbps) ports
LAN	2x 10G SFP+ ports 2x 10GBase-T LAN ports 4x 1GbE LAN ports 1 Dedicated IPMI LAN port
USB	2 USB 3.0 ports (rear)
Display	1 VGA port
TPM	1 TPM 2.0 header


Chassis

Form Factor	Compact
Model	CSE-E300


Dimensions

Width	10" (254mm) / 15" (381mm) - pkg.
Height	1.7" (43mm) / 10.87" (276mm) - pkg.
Depth	8.9" (226mm) / 5.59" (142mm) - pkg.
Weight	Gross Weight: 7.5 lbs (3.4 kg) Net Weight: 3.45 lbs (1.56 kg)
Available Colors	Black


Front Panel

Buttons	Power On/Off button
LEDs	Power LED (Hard drive activity LED)


Expansion Slots

PCI-Express	1 PCI-E 3.0 x8 slot


Drive Bays

Internal	1 Fixed 2.5" drive bay with bracket (when AOC area is not occupied)


System Cooling

Fans	3x 40x28mm 4-PIN PWM Fan


Power Supply

DC Power Adapter with PFC


System BIOS

BIOS Type	128Mb SPI Flash with AMI BIOS
BIOS Features	PCI 3.0 ACPI 5.0 USB Keyboard support Hardware BIOS Virus protection SMBIOS 2.8 UEFI 2.4 RTC (Real Time Clock) Wakeup


Management

Software	Intel® Node Manager IPMI 2.0 KVM with dedicated LAN NMI SUM SuperDoctor® 5 Watch Dog
Power Configurations	ACPI Power Management +12V DC Power Input Control of power-on for recovery from AC power loss CPU thermal trip support for processor protection M.2 NGFF connector, Node Manager Support, SDDC, System level control, UID, WOL
Fan	Fans with tachometer status monitoring Status monitor for speed control Low noise fan speed control Pulse Width Modulated (PWM) fan connectors


Operating Environment / Compliance

RoHS	RoHS Compliant
Environmental Spec.	Operating Temperature: 0°C to 40°C (32°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)

Parts List


Parts List - (Items Included)

	Part Number	Qty	Description
Motherboard / Chassis	MBD-X11SDV-4C-TP8F CSE-E300	1 1	Super X11SDV-4C-TP8F Motherboard Embedded Server BOX for Flex-ATX, Mini-ITX 1U height
Power Adapter	MCP-250-10128-0N	1	150W Lockable Power Adapter with US power cord
Cooling Fan	FAN-0100L4	3	4028mm 8.5K RPM 4-PIN PWM FAN


Optional Parts List

	Part Number	Qty	Description
Added-On-Card	AOC-SLG3-2M2-O	-	Added-On-Card; Supports 2pcs 22x80mm or 22x110mm NVMe M.2 (Note: If the Added-On-Card is installed, no SSD can be installed then)
Riser Card	RSC-RR1U-E8	-	RSC-RR1U-E8 (Rev 4.00) Riser Card
Chassis Parts	MCP-290-30002-0B	-	CSE-E300 Rackmount kit (150W/180W adapter supported)
