- 19" Intel® 8th Fanless Stainless Panel PC
- IP66/69K Full Sealed with Anti-Corrosion Enclosure
- Support Intel® vPro technology by CPU
- Optional IP67 M12 Stainless Connectors
- Optional Cable Gland for External I.O.
- Special Inspection of 100% Waterproof Guarantee
- CE, FCC, VCCI Class B Certified
- Screen Touch Lock Function
IP66/69K Stainless Steel Panel PC WTP-9G66 Whiskey Lake 19"
- 19" Intel® 8th Fanless Stainless Panel PC
- IP66/69K Full Sealed with Anti-Corrosion Enclosure
- Support Intel® vPro technology by CPU
- Optional IP67 M12 Stainless Connectors
- Optional Cable Gland for External I.O.
- Special Inspection of 100% Waterproof Guarantee
- CE, FCC, VCCI Class B Certified
- Screen Touch Lock Function
| Model | WTP-9G66-19 | |||
|---|---|---|---|---|
| Main System | ||||
| CPU / Chipset | FCBGA1356 8th generation Intel® Core i7/i5 processor 15W max. / Soc | |||
| Graphic | Intel® integrated HD Graphics | |||
| RAM |
Dual channel support 2666MHz DDR4 SODIMM socket x 2,up to 32GB
|
|||
| OS Support | Windows 10 (64 bit) / Windows 11 (64 bit) | |||
| Storage | 2.5” SATA drive bay x 1 | |||
| Expansion | Mini PCIe x 1, M.2 Type E x 1 | |||
| Display Size | 19” TFT-Color LCD (5:4) | |||
| Display | 1280 x 1024(SXGA), 160(H) / 160(V), 450 nits (Typ. Center point), CR:600 : 1 (Typ) | |||
| Touch Screen | Full Flat Resistive touch / Light Transmission: 80 ± 5% / Hardness: 4H | |||
| I.O. Ports | ||||
| Configuration | STD. (M12 Connector) | Cable Gland (Max. 5 external I/O by proper grommet) | ||
| USB | 1 x M12 8pin for USB 1/2 (USB2.0), 1 x M12 8pin for USB 3/4(USB2.0) | USB 3.1 x 4 | ||
| COM | 2 x M12 8pin for COM 1/COM2 / RS-232/422/485 |
RS232/RS422/RS485 x 2
|
||
| LAN | 1 x M12 8pin for LAN x 1 ( i219LM for Vpro ) | RJ-45 x 2 (Gigabit Ethernet) | ||
| Audio | N.A. | 3.5mm phone jack connector * 2 (Line-out, and Mic-in) | ||
| Video | N.A. | HDMI 2.0a x 1, DP1.2 x 1 | ||
| Control Key | Rear bottom: Power on/off | |||
| Mechanical and Environmental | ||||
| Cooling | Fanless | |||
| Power Input / Consumption | DC 19V~28V / 90W | |||
| Power Adapter | AC 100 ~ 277V / 47 ~ 63 Hz / DC output 12V, IP68 | |||
| Temperature |
Operating Temperature
24V DC Input 0~40℃/ 0~50℃ (Change to SSD)
Storage Temperature -20~60℃
|
|||
| Humidity | Operating & Storage: 10 ~ 90%, non-condensing | |||
| IP Rating / Housing | IP66, NEMA4X , IP69K/ SUS304 stainless steel enclosure, chassis type | |||
| Dimensions (Net) | 458 mm (H) x 386 mm (V) x 64 mm (T) | |||
| Weights (Net) | 11.5 kg (w/o power adapter/battery pack) | |||
| Mounting | VESA 100, side mount (M6*2) | |||
| Certification | CE (EMC) :EN61000-6-4 ; EN61000-6-2 / FCC/VCCI Class B, Canada ICES-003 | |||
WTP-9G66-19
