WMP-24K

Médical Panel PC WMP-24K Wincomm

Wincomm WITH FAN Panel PC WMP-24K Medical AI Coffee Lake 23.8"

  • Intel® 8th/9th Generation Core i7/i5 CPU
  • 23.8" 16:9 1920 x 1080 FHD Diagnostic Panel
  • Medical Latest MDR/EN/UL 60601-1 & 60601-1-2 Certifications
  • Anti-bacteria Hospital White Plastic Housing
  • Front IP65 Ingress Protection & IPX1 Whole System
  • Optional Independent GeForce RTX 2060 Graphic Card
  • Optional PCIe Expansion for Intel® Movidius™ AI Kits
Model WMP 24K IPOA (STD)                       　　　 WMP 24K IPOB (ISO)
Main System
CPU / Chipset Intel® 8th / 9th generation Core i7/i5 /Pentium/Celeron Processor (35W Max.)
Graphic Intel® integrated HD Graphics 630 by CPU
RAM Two 2666 MHz DDR4 SODIMM socket support dual Channel, non-ECC, up to 64GB
OS Support Windows 10
Storage
M.2 M.Key 2280 PCIe X 4 NVMe SSD Up to 1TB
Optional 2nd 2.5” SATA III SSD/HDD Up to 2 TB
Expansion 1 x PCI-e(x4) (25W Max.),  1 x M.2 E Key 2230
Optional Network Interface: 802.11 ac/a/b/g/n WLAN + Bluetooth module or WiFi-6
Display Size 23.8” 16:9 TFT-LCD (LED Backlight)
Display (FHD) 1920 x 1080 (Full HD), 16.7M colors (MVA, 8 bit), 178(H) / 178(V),
250 nits (Typ. Center point), CR:3000 : 1 (Typ)
Touch Screen Full flat projective capacitive touch panel /  Light Transmission: 90% ± 3% / Hardness: 7H pencil, pressure 750g/45° / Life: 100M times
I.O. Ports
USB USB3.1 Gen II x 4 USB3.1 Gen II x 4, ISO USB2.0 x 1
COM RS-232 x 1, RS232/RS422/RS485 X 1 1 x RS-232, 1 x RS232/RS422/RS485
1 x ISO RS-232, 1 x ISO RS232/RS422/RS485
LAN RJ45 X 2 RJ45 X 2, ISO RJ45 x 1
Audio 3.5mm phone jack connector * 2 (Line-out, Mic-In)
Video Out DP x 2
Control Hot Key (R to L) Power // Audio adjustment // brightness // Reading Light // Video input selection // LCD on/off //
Clean me(auto release after 1 minute) // Fn
Mechanical and Environmental
Cooling Smart Fan
Power Input  DC-In x 1, DC 14~19V input
Power Adapter / Battery AC input 100 ~ 240V/ 47~63 Hz/ DC output 19V/ 250W // DR-202W2
Temperature Operating Temperature: 0~40℃ / Storage Temperature: -20~60℃
Humidity Operating & Storage: 10 ~ 90%, non-condensing
IP Rating / Housing IP65 (Front Side)  IPX1 for whole system / Plastic White w/Anti-bacteria (MRSA), Housing & Touch Screen
Dimensions (Net) 594.0mm (W) x 397.0mm (H) x 84.1mm (D)
Weights (Net) 9.0 KG (approximate, w/o power adapter)
Mounting Optional Stand, VESA 100
Certification
FCC (part 18 Class B) / CE (EN 60601-1-2 ver. 4.0) / VCCI (2016-11, class B)
UL: ANSI/AAMI ES60601-1:2012 (V3.1)
cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1) / MDR (2017/745)
WMP-24K
