Wincomm FANLESS PANEL PC WMP-15J Whiskey Lake 15"
- Powerful Intel® Whiskey Lake Core i CPU
- Medical Latest 60601-1 & 60601-1-2 Certifications
- 15.6" Wide LCD Panel w/ P-Cap Multi-Touch
- Optional Built-In UPS Battery Pack
- Fanless Design with Reliable Thermal Solution
- Dual storage with M.2 SSD & 2.5”Drive
- Hospital White Plastic Housing with Anti-bacteria Treatment
- 4KV Isolated I/O Kit and More Options for Diversified Applications
- Support PCIex4 Expansion Slot
Médical Panel PC WMP-15J Wincomm
Wincomm FANLESS PANEL PC WMP-15J Whiskey Lake 15"
- Powerful Intel® Whiskey Lake Core i CPU
- Medical Latest 60601-1 & 60601-1-2 Certifications
- 15.6" Wide LCD Panel w/ P-Cap Multi-Touch
- Optional Built-In UPS Battery Pack
- Fanless Design with Reliable Thermal Solution
- Dual storage with M.2 SSD & 2.5”Drive
- Hospital White Plastic Housing with Anti-bacteria Treatment
- 4KV Isolated I/O Kit and More Options for Diversified Applications
- Support PCIex4 Expansion Slot
Specification
| Model | WMP 15J IPOA (STD) | WMP 15J IPOB (ISO) |
|---|---|---|
| Main System | ||
| CPU / Chipset |
FCBGA1528 8th generation Intel® Core i7/i5 processor (15W Max.)
Optional Vpro by Core i7/i5 CPU/ SoC
|
|
| Graphic | Intel® integrated UHD Graphics 620 | |
| RAM | Two DDR4 Dual-2400MHz RAM, non-ECC, x2 SO-DIMM socket, up to 64GB | |
| OS Support | Optional Win 10 IoT Enterprise | |
| Storage |
2.5” SSD/HDD / M.2 SSD (M Key 2242/2260/2280) PCIe x4 & SATA3
|
|
| Expansion |
1 x PCIex4, 1 x M.2 E Key
Optional Network Interface: 802.11 ac/a/b/g/n WLAN + Bluetooth Module
|
|
| Display Size | 15.6” wide TFT-Color LCD (16:9) | |
| Display |
1366 x 768, 16.7M colors, 170(H) / 160(V), 400 nits, CR:500 : 1 (Typ)
|
|
| Touch Screen |
Full Flat P-cap Touch Panel / Light Transmission: 90% ± 3% / Hardness: 7H pencil, pressure 750g/45° / Life: 100M times
|
|
| I.O. Ports | ||
| USB | 4 x USB3.1 gen. II | 4 x USB3.1 gen. II, 1 x ISO USB2.0 |
| COM |
1 x RS232/422/485, 1 x RS232
|
1 x RS232/422/485, 1 x RS232, 1 x ISO RS-232, 1 x ISO RS232/RS422/RS485 |
| LAN | Gigabit / 2 x RJ45 | Gigabit / 2 x RJ45, 1 x ISO RJ45 |
| Audio | 2 x 3.5mm phone jack connector (Line-out, Mic-In) | |
| Video Out | 1 x DP1.2, 1 x HDMI 1.4 | |
| Control Hot Key (R to L) |
Power Button, Mute,Volume adjustment (-),Volume adjustment (+),Brightness (-),Brightness (+),LCD on/off,Clean me,Dis-webcam,Function key
|
|
| Mechanical and Environmental | ||
| Cooling | Fanless Design with External Heatsink | |
| Power Input | DC-In x 1, DC 14~24V input | |
| Power Adapter | AC input 100~240V / 47 ~ 63 Hz / DC output 18V, 100W, Universal Type | |
| Temperature | Operating Temperature: 0~40℃ (chamber) / Storage Temperature: -20~60℃ | |
| Humidity | Operating & Storage:10 ~ 90%, non-condensing | |
| IP Rating / Housing | IP65 (Front Side), IPx1 whole system / Front: Full flat design/ Touch (standard)/ Glass( customized); Rear: Plastic White w/Anti-bacteria (MRSA) Housing | |
| Dimensions (Net) | 430 mm (H) x 300 mm (V) x 90 mm (T) | |
| Weights (Net) | 5 kg (w/o power adapter/battery pack) | |
| Mounting | Optional Stand, VESA 75/100 | |
| Certification |
MDR (2017/745)(by Project), EN/UL(60601-1:2012, V3.1)(by Project)/cUL60601-1:2014 (V3.1)(by Project)/FCC/CE(60601-1-2: 2015(V4.0)/VCCI Class B
|
|
WMP-15J
