Wincomm Fanless Panel-PC Médicale 24" WMP-24J Hot-Swappable Batteries
- Mobile Intel® Whiskey Lake Core i CPU
- Medical Latest IEC 60601-1 & 60601-1-2 Certifications (MDR)
- 23.8" FHD MVA Diagnostic Panel w/ P-Cap Multi-Touch
- Hot-Swappable Batteries X3 Capacity
- Fanless Design with Reliable Thermal Solution
- Dual storage w/ M.2 NVMe SSD & 2.5” drive (w/doggy door)
- Hospital white plastic housing with anti-bacteria treatment
- 4KV isolated I/O kit, DICOM GSDF Calibration and More Options for Diversified Applications
- Support PCIex4 Expansion Slot
Médical Panel PC WMP-24J Wincomm
Wincomm Fanless Panel-PC Médicale 24" WMP-24J Hot-Swappable Batteries
- Mobile Intel® Whiskey Lake Core i CPU
- Medical Latest IEC 60601-1 & 60601-1-2 Certifications (MDR)
- 23.8" FHD MVA Diagnostic Panel w/ P-Cap Multi-Touch
- Hot-Swappable Batteries X3 Capacity
- Fanless Design with Reliable Thermal Solution
- Dual storage w/ M.2 NVMe SSD & 2.5” drive (w/doggy door)
- Hospital white plastic housing with anti-bacteria treatment
- 4KV isolated I/O kit, DICOM GSDF Calibration and More Options for Diversified Applications
- Support PCIex4 Expansion Slot
Specification
| Model | WMP 24J IPOA (STD) | WMP 24J IPOB (ISO) | |
|---|---|---|---|
| Main System | |||
| CPU / Chipset | FCBGA1528 Intel® Whiskey Lake Core i7/i5 processor (15W Max.) Optional Vpro by Core i7/i5 CPU | ||
| Graphic | Intel® integrated HD Graphics 620 | ||
| RAM | Two DDR4 Dual-2400MHz RAM, non-ECC, x2 SO-DIMM socket, up to 64GB | ||
| OS Support | Win 10 IoT Enterprise | ||
| Storage | 1 x M.2 NVMe SSD (M Key 2242/2260/2280) PCIex4, 1 x 2.5” SSD/HDD w/ doggy door | ||
| Expansion | 1 x PCIex4 (25W Max.), 1 x M.2 Type E Optional Network Interface: 802.11 ac/a/b/g/n (or Wifi-6) WLAN + Bluetooth module | ||
| Display Size | 23.8” wide TFT-Color LCD (16:9) | ||
| Display | 1920 x 1080 (Full HD), 16.7M colors, 178(H) / 178(V), 250 nits (Typ. Center point), CR:3000 : 1 (Typ) |
||
| Touch Screen | Full flat projective capacitive touch panel / Light Transmission: 90% ± 3% / Hardness: 7H pencil, pressure 750g/45° / Life: 100M times | ||
| I.O. Ports | |||
| USB | 4 x USB3.1 gen II | 4 x USB3.1 gen II 1 x ISO USB2.0 4 x USB3.1 gen II |
|
| COM | 1 x RS-232, 1 x RS232/RS422/RS485 |
1 x ISO COM RS232 1 x RS232/RS422/RS4851 x RS-232, 1 x RS232/RS422/RS485 |
|
| LAN | 2 x Gigabit RJ45 | 2 x Gigabit RJ45, ISO LAN x 12 x Gigabit RJ45 | |
| Audio | 3.5mm phone jack connector * 2 (Line-out, Mic-In) | ||
| Video Out | 1 x DP, 1 x HDMI video-in1 x DP | ||
| Reading light | Light bar x 2 (at housing bottom side) | ||
| Control Hot Key (R to L) | Battery LED Indicator, Power On/Off, Volume +/-, Brightness +/-, Reading Light, LCD Backlight On/Off, Touch Hot Key Enable/Disable, Function Key |
||
| Mechanical and Environmental | |||
| Cooling | Fanless | ||
| Battery Pack | Optional 3 x DR-202 Series, Lithium-ion Battery w/ Hot-Swappable Design | ||
| Power Input | DC-In x 1, DC 14~24V input | ||
| Power Adapter | AC input 100~240V / 47 ~ 63 Hz / DC output 24V, 180W | ||
| Temperature | Operating Temperature: 0~40℃ (chamber) / Storage Temperature: -20~60℃ | ||
| Humidity | Operating & Storage:10 ~ 90%, non-condensing | ||
| IP Rating / Housing | IP65 (Front Side),IPX1 for whole system / Front: Full flat design/ Touch (standard)/ Glass( customized); Rear: Plastic White w/Anti-bacteria (MRSA), Housing |
||
| Dimensions (Net) | 594 x 397 x 56 mm | ||
| Weights (Net) | 9.0 kg (w/o power adapter/battery pack) | ||
| Mounting | Optional Stand, VESA 100 | ||
| Certification |
MDR (2017/745), UL/cUL60601-1:2014 (V3.1)/,
FCC/CE(60601-1-2: 2015(V4.0)/VCCI Class B
|
||
WMP-24J
