WMP-22J

Médical Panel PC WMP-22J Wincomm

Wincomm Fanless Panel-PC Médicale 22" WMP-22J Hot-Swappable Batteries

  • Mobile Intel® Whiskey Lake Core i CPU
  • Medical Latest IEC 60601-1 & 60601-1-2 Certifications (MDR)
  • 21.5" FHD MVA Diagnostic Panel w/ P-Cap Multi-Touch
  • Hot-Swappable Batteries X3 at 243Wh Capacity
  • Fanless Design with Reliable Thermal Solution
  • Dual storage M.2 NVMe SSD & 2.5” drive (w/ doggy door)
  • Hospital white plastic housing with anti-bacteria treatment
  • 4KV isolated I/O kit, DICOM GSDF calibration and more options for diversified applications
  • Support PCIex4 Expansion Slot
Specification
Model WMP 22J IPOA (STD) WMP 22J IPOB (ISO)
Main System
CPU / Chipset FCBGA1528 Intel® Whiskey Lake Core i7/i5 processor (15W Max.) Optional Vpro by Core i7/i5 CPU/ SoC
Graphic Intel® integrated HD Graphics 620
RAM DDR4 Dual-2400MHz, SO-DIMM socket, non-ECC, up to 64GB
OS Support Win 10 IoT Enterprise
Storage 1 x M.2 NVMe SSD (M Key 2242/2260/2280) PCIex4, 1 x 2.5” SSD/HDD w/ doggy door
Expansion 1 x PCIex4, 1 x M.2 E Key
Optional Network Interface: 802.11 ac/a/b/g/n WLAN + Bluetooth module
Display Size 21.5” wide TFT-Color LCD (16:9)
Display Option 1: 1920 x 1080 (Full HD), 16.7M colors (Ture,8 bit), 178(H) / 178(V), 250 nits (Typ. Center point), CR:3000 : 1 (Typ)
Option 2: 1920 x 1080 (Full HD), 16.7M colors (Ture,8 bit), 178(H) / 178(V), 250 nits (Typ. Center point), CR:1000 : 1 (Typ)
Touch Screen Full flat projective capacitive touch panel /  Light Transmission: 90% ± 3% / Hardness: 7H pencil, pressure 750g/45° / Life: 100M times
I.O. Ports
USB 4 x USB3.1 gen II 4 x USB3.1 gen II,
1 x ISO USB 2.0　　　　　　　　　　　　　　　　
COM 1 x RS-232,
1 x RS232/RS422/RS485		 1 x ISO RS-232,
1 x ISO RS232/RS422/RS485　　　　　　　　　　　　　　　　　　　　
LAN 2 x Gigabit RJ45 2 x Gigabit RJ45, 1 x ISO Gigabit RJ45
Audio 2 x 3.5mm phone jack connector (Line-out, Mic-In)
Video Out 1 x DP & 1 x HDMI video-in
Reading light Light bar x 2 (at housing bottom side)
Control Hot Key (R to L) Battery LED Indicator, Power On/Off, Volume +/-, Brightness +/-, Reading Light, LCD Backlight On/Off, Touch & Hot Key Enable/Disable, Function Key
Mechanical and Environmental
Cooling Fanless Design with External Heatsink
Battery Pack Optional 3 x DR-202 Series, Lithium-ion Battery w/ Hot-Swappable Design
Power Input
& Adapter Spec		 DC-In x 1, DC 14-24V input/ AC input 100~240V / 47 ~ 63 Hz / DC output 18V, 100W (Optional 180W)
Temperature Operating Temperature: 0~40℃ (chamber) / Storage Temperature: -20~60℃
Humidity Operating & Storage:10 ~ 90%, non-condensing
IP Rating / Housing IP65 (Front Side),IPX1 for whole system / Front: Full flat design/ Touch (standard)/ Glass( customized); Rear: Plastic White w/Anti-bacteria (MRSA), Housing
Dimensions (Net) 541.0mm(H) x 413.14mm(V) x 56.0 mm(T)
Weights (Net) 7.0 kg (w/o power adapter/battery pack)
Mounting Optional Stand, VESA 100
Certification MDR (2017/745), UL/cUL60601-1:2014 (V3.1)/,
FCC/CE(60601-1-2: 2015(V4.0)/VCCI Class B
