Wincomm FANLESS PANEL PC WMP-15J Whiskey Lake 15"

  • Powerful Intel® Whiskey Lake Core i CPU
  • Medical Latest 60601-1 & 60601-1-2 Certifications
  • 15.6" Wide LCD Panel w/ P-Cap Multi-Touch
  • Optional Built-In UPS Battery Pack
  • Fanless Design with Reliable Thermal Solution
  • Dual storage with M.2 SSD & 2.5”Drive
  • Hospital White Plastic Housing with Anti-bacteria Treatment
  • 4KV Isolated I/O Kit and More Options for Diversified Applications
  • Support PCIex4 Expansion Slot


Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Specification
Model WMP 15J  IPOA (STD) WMP 15J  IPOB (ISO)
Main System
CPU / Chipset
FCBGA1528 8th generation Intel® Core i7/i5 processor (15W Max.)
Optional Vpro by Core i7/i5 CPU/ SoC
Graphic Intel® integrated UHD Graphics 620
RAM Two DDR4 Dual-2400MHz RAM,  non-ECC, x2 SO-DIMM socket,  up to 64GB
OS Support Optional Win 10 IoT Enterprise
Storage
2.5” SSD/HDD / M.2 SSD (M Key 2242/2260/2280) PCIe x4 & SATA3
Expansion
1 x PCIex4, 1 x M.2 E Key
Optional Network Interface: 802.11 ac/a/b/g/n WLAN + Bluetooth Module
Display Size 15.6” wide TFT-Color LCD (16:9)
Display
1366 x 768, 16.7M colors, 170(H) / 160(V), 400 nits, CR:500 : 1 (Typ)
Touch Screen
Full Flat P-cap Touch Panel /  Light Transmission: 90% ± 3% / Hardness: 7H pencil, pressure 750g/45° / Life: 100M times
I.O. Ports
USB 4 x USB3.1 gen. II 4 x USB3.1 gen. II, 1 x ISO USB2.0
COM
1 x RS232/422/485, 1 x RS232
1 x RS232/422/485, 1 x RS232, 1 x ISO RS-232, 1 x ISO RS232/RS422/RS485
LAN Gigabit / 2 x RJ45 Gigabit / 2 x RJ45,  1 x ISO RJ45
Audio 2 x 3.5mm phone jack connector (Line-out, Mic-In)
Video Out 1 x DP1.2, 1 x HDMI 1.4
Control Hot Key (R to L)
Power Button, Mute,Volume adjustment (-),Volume adjustment (+),Brightness (-),Brightness (+),LCD on/off,Clean me,Dis-webcam,Function key
Mechanical and Environmental
Cooling Fanless Design with External Heatsink
Power Input DC-In x 1,  DC 14~24V input
Power Adapter AC input 100~240V / 47 ~ 63 Hz / DC output 18V, 100W, Universal Type
Temperature Operating Temperature: 0~40℃ (chamber) / Storage Temperature: -20~60℃
Humidity Operating & Storage:10 ~ 90%, non-condensing
IP Rating / Housing IP65 (Front Side), IPx1 whole system / Front: Full flat design/ Touch (standard)/ Glass( customized); Rear: Plastic White w/Anti-bacteria (MRSA) Housing
Dimensions (Net) 430 mm (H) x 300 mm (V) x 90 mm (T)
Weights (Net) 5 kg (w/o power adapter/battery pack)
Mounting Optional Stand, VESA 75/100
Certification
MDR (2017/745)(by Project), EN/UL(60601-1:2012, V3.1)(by Project)/cUL60601-1:2014 (V3.1)(by Project)/FCC/CE(60601-1-2: 2015(V4.0)/VCCI Class B
