Carte mère Supermicro H12SSW-IN

1.Single AMD EPYC™ 7003/7002 Series Processor
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)

2.2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs

3.Expansion slots:
1 PCI-E 4.0 x32 Left Riser Slot
1 PCI-E 4.0 x16 Right Riser Slot
M.2 Interface: 2 SATA/PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-key

4.16 SATA3, 2 M.2, 2 SuperDOM

5.2 NVMe via SlimSAS,
4 NVMe or 16 SATA3 via SlimSAS,
2 M.2,
2 SATA3

6.1 Realtek RTL8211E PHY (dedicated IPMI)

7.ASPEED AST2500 BMC graphics

8.Up to 7 USB 3.0 ports

9.6x 4-pin PWM Fans & Speed control

Product SKUs
MBD-H12SSW-iN
  • H12SSW-iN

Physical Stats
Form Factor
  • Proprietary WIO
Dimensions
  • 8.15" x 13.05"

Processor/Chipset
CPU
  • Single AMD EPYC™ 7003/7002 Series Processor
    (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
  • Socket SP3
Cores
  • Up to 64 Cores
Chipset
  • System on Chip

System Memory
Memory Capacity
  • 8 DIMM slots
  • Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
  • 8-channel memory bus
Memory Type
  • DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
DIMM Sizes
  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices
SATA
  • SATA3 (6 Gbps)
IPMI
  • Support for Intelligent Platform Management Interface v. 2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
Network Controllers
  • 2x 1GbE LAN Ports via Broadcom BCM5720L
  • 1 Realtek RTL8211E PHY (dedicated IPMI)
VGA
  • ASPEED AST2500 BMC

Input / Output
SATA
  • 2 SATA3 (6 Gbps) ports
SATA/NVMe Hybrid
  • 16 SATA3 / 4 NVMe (PCI-E Gen3)
NVMe
  • 2 NVMe (PCI-E Gen4)
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 7 USB 3.0 ports (4 rear, 2 via header, 1 Type A)
VGA
  • 1 VGA port
Others
  • 1 COM port
  • 2 SuperDOM power connectors
  • 1 TPM 1.2/2.0 header

Expansion Slots
PCI-Express
  • 1 PCI-E 4.0 x32 Left Riser Slot
  • 1 PCI-E 4.0 x16 Right Riser Slot
M.2
  • Interface: 2 SATA/PCI-E 3.0 x2
  • Form Factor: 2280, 22110
  • Key: M-key
Chassis (Optimized for H12SSW-iN)
1U
2U

System BIOS
BIOS Type
  • AMI 256Mb SPI Flash EEPROM
BIOS Features
  • Plug and Play (PnP)
  • DMI 2.3
  • PCI 2.2
  • ACPI 5.1
  • USB Keyboard Support
  • SMBIOS 3.1.1

Management
Software
Power Configurations
  • ACPI Power Management
  • Power-on mode control for AC power loss recovery

PC Health Monitoring
CPU
  • Monitors CPU Core Voltages, +1.5V, +1.8V, +12V, +5V, +5V standby
  • CPU switching voltage regulator
FAN
  • Up to 6 fan status tachometer monitoring
  • Up to 6 4-pin fan headers
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU Thermal Trip Support
  • Thermal control for 6x Fan connectors
  • I²C Temperature Sensing Logic
LED
  • CPU / System Overheat LED
Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header

Operating Environment / Compliance
Environmental Specifications
  • Operating Temperature:
       10°C to 35°C (50°F to 95°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
Parts List
Retail Pack List
  Part Number Qty Description
H12SSW-iN MBD-H12SSW-iN -O 1 H12SSW-iN Motherboard
Optional Parts List
  Part Number Qty Description
TPM security module AOM-TPM-9655V - TPM 1.2 module with Infineon 9655, RoHS/REACH,PBF;
AOM-TPM-9665V - TPM 2.0 module with Infineon 9665, RoHS/REACH,PBF;
