Châssis Supermicro CSE-101I

  1. Slim & Space-saving Chassis Design
  2. Optional 60W/80W DC-in Power adapter or
    DC/DC Power converter board
  3. 1x 2.5" internal HDD support
  4. 1x 6cm Cooling Fan
  5. Front I/O: 2x USB 2.0 & 2x Audio port
  6. Power switch w/ 1x LED
  7. VESA/Wall-mount ready
Product SKUs
CSE-101i
  • SuperChassis 101i

Form Factor
  • Mini-ITX chassis support for motherboard size Mini-ITX 6.75" x 6.75"

Processor Support
  • Intel® Atom™ processors
  • Single Intel® and AMD processors

Dimensions
Height
  • 2.68" (68 mm)
Width
  • 7.68" (195 mm)
Depth
  • 7.68" (195 mm)
Gross Weight
  • 7.5 lbs (3.4 kg)
Net Weight
  • 2.76 lbs (1.25 kg)
Packaging (W x H x L)
  • 15" (381 mm) x 10.87" (276 mm) x 5.59" (142 mm)
Available Color
  • Black

Drive Bays
  • 1x 2.5" fixed drive bay
  • Enterprise SATA HDD only recommended

Front Panel
Button
  • Power On/Off button
LED
  • Power status LED
  • HDD activity LED
  • Power off LED
Port
  • 2x USB 2.0 Port(s)
  • 2x Audio Jack(s)
Systems Cooling
Fans
  • 1x 6cm 4-pin high performance cooling fan(s)

Operating Environment (System)
Operating Temperature Range
  • 0°C - 40°C (32°F - 104°F)
Non-Operating Temperature Range
  • -20°C - 60°C (-4°F - 140°F)
Operating Relative Humidity Range
  • 10% - 85% (non-condensing)
Non Operating Relative Humidity Range
  • 10% - 95% (non-condensing)

Power Supply
Optional 60W/84W, DC-DC Power Adapter or DC/DC Power converter board
Certification
  • N/A

Regulatory (Power Supply)
Power Supply Safety / EMC
  • CCC
  • CE/EMC
  • FCC
  • TUV/CB
  • UL/CUL
Components

Standard Parts List
  Part Number Qty Description
Part(s) MCP-270-10101-0B 1 Chassis base for CSE-101i
Part(s) MCP-290-10101-0B 1 Chassis
Part(s) MCP-290-10102-0N 1 CSE-101i HDD bracket support bar
Part(s) MCP-290-10103-0N 1 CSE-101i HDD bracket
Front Panel FPB-FP101-U2 1 Front control board for CSE-101i with USB2.0 and audio
Optional Parts List
  Part Number Qty Description
Cable CBL-0296L •logo_eStore.jpg - 9" 4 pin fan extension cord, for fan guide pin at 1&3 or 1&4
CBL-0080L •logo_eStore.jpg - SATA Power Adapter Cable 6"
Chassis parts MCP-290-10108-0B - Dual system tray for Mini-ITX system
Power Adapter MCP-250-10117-0N •logo_eStore.jpg - 60W DC power adapter with US power cord 18AWG 6ft
MCP-250-10122-0N - 84W DC power adapter with US power cord 18AWG 6ft
Power Board MCP-250-10103-0N - 80W DC-ATX PWR Board
CSE-101I
