SYS-5019A-FN5T

Supermicro SuperServer SYS-5019A-FN5T

1. Intel® Atom® processor C3958,
    Single socket FCBGA 1310;
    16-Core, TDP 31W

2. 1x 3.5" or 2x 2.5" internal drive bays

3. 1 PCI-E 3.0 x8,
    1 M-Key 2242/2280, PCI-E 3.0 x2/SATA,
    1 B-Key 3042/2280, PCI-E 3.0 x2/SATA/USB

4. Up to 256GB ECC RDIMM DDR4
    2400MHz or 64GB ECC/non-ECC
    UDIMM in 4 DIMM slots

5. 4x 10GbE LAN,
    1x 1GbE LAN (IPMI shared LAN)

6. USB 3.0 (4 front Type-A),
    1 VGA, 1 SuperDOM, TPM

7. 3x 40x28mm 4-pin PWM fans

8. 200W Low-noise AC-DC power supply

9. Intel® Quick Assist Technology

Product SKUs
SYS-5019A-FN5T
  • SuperServer 5019A-FN5T (Black)

Motherboard

Super A2SDV-16C-TLN5F

Processor
CPU
  • Intel® Atom® processor C3958
  • FCBGA 1310 supported
  • CPU TDP support 31W

System Memory
Memory Capacity
  • 4x DDR4 DIMM sockets
  • Supports up to 256GB DDR4 ECC RDIMM
  • Supports up to 64GB DDR4 ECC/non-ECC UDIMM
Memory Type
  • 2400/2133/1866/1600MHz ECC DDR4 SDRAM
DIMM Sizes
  • 64GB, 32GB, 16GB, 8GB, 4GB
Memory Voltage
  • 1.2 V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors
      (using ECC memory)

On-Board Devices
SATA
  • SoC controller for 2 SATA3 (6Gbps) ports
Network Controllers
  • Quad 10GBase-T LAN with Intel® X557
  • Single Gigabit Ethernet LAN with Intel® i210
IPMI
  • Aspeed AST2400 BMC
Graphics
  • Aspeed AST2400 integrated VGA

Input / Output
SATA
  • 2 SATA3 (6Gbps) ports
LAN
  • 4x 10GbE LAN ports
  • 1x 1GbE LAN (IPMI shared LAN)
USB
  • 5 USB 3.0 (4 rear, Type-A)
  • 2 USB 2.0 (2 via headers)
Serial Port
  • 1 COM via RJ45
DOM
  • 1 SATA DOM (Disk on Module) power connector
VGA
  • 1 VGA Port
Others
  • TPM header
Chassis
Form Factor
  • 1U Rackmount
Model

Dimensions and Weight
Height
  • 1.7" (43mm)
Width
  • 17.2" (437mm)
Depth
  • 9.8" (249mm)
Weight
  • Net Weight: 8 lbs (3.62 kg)
  • Gross Weight: 12 lbs (5.44 kg)
Available Colors
  • Black

Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power LED
  • Hard drive activity LED
  • Network activity LEDs
  • System Information LED
  • Information LED (temp., status)

Expansion Slots
PCI-E
  • 1 PCI-E 3.0 x8
  • 1 M-Key 2242/2280 , PCI-E 3.0 x2/SATA
  • 1 B-Key 3042/2280 PCI-E 3.0 x2/SATA/USB

Drive Bays
HDD
  • 1x 3.5" or 2x 2.5" internal hard drive bays

System Cooling
Fans
  • 3x 40x28mm 4-PIN PWM Fan (FAN-0065L4, 13K RPM)

Power Supply
200W Low Noise AC-DC power supply with PFC
AC Voltage
  • 100 - 240V, 50-60Hz, 2.6 Amp Max
+5V
  • 8.0 Amp (max.)
+5V standby
  • 2.0 Amp (max.)
+12V
  • 16 Amp (max.)
-12V
  • 0.5 Amp (max.)
+3.3V
  • 8.0 Amp (max.)
Certification Gold Level Certified
  Gold Certified


System BIOS
BIOS Type
  • AMI UEFI BIOS
BIOS Features
  • UEFI 2.4
  • SMBIOS 2.7.1

Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       0°C to 40°C (32°F to 104°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
