SYS-E300-9D-8CN8TP Supermicro

SYS-E300-9D-8CN8TP

Supermicro Serveur SYS-E300-9D-8CN8TP Embedded/IoT E300-9D-8CN8TP

Network Security Appliance
Universal Customer Premise
   Equipment (uCPE)
Software Defined WAN (SD-WAN)
NFV Edge Computing Server
Virtualization Server
IoT Edge Computing / Gateway

1. Intel® Xeon® processor D-2146NT,
    8-Core, 16 Threads, 80W

2. System on Chip

3. 1 Fixed 2.5" drive bay with bracket

4. 1 M.2 slot M key for SSD, 2242/80,
    1 M.2 B Key for SSD/ WAN card,
    1 Mini-PCI-E with mSATA Support,
    1 PCI-E 3.0 x8 slot

5. Up to 512GB ECC LRDIMM,
    up to 256GB ECC DIMM
    DDR4-2666Mz; in 4 DIMM slots

6. 4x 1GbE, 2x 10GBase-T, 2x 10G SFP+
    and 1 dedicated LAN for IPMI 2.0

7. 1 VGA, 2 USB 3.0

8. 3x 40x28mm 4-PIN PWM Fan

9. Low-noise DC Power Supply

10. Built in Intel QAT up to 40Gbps
    Crypto/Compression



Garanties sécurité (à modifier dans le module "Réassurance")



Politique de livraison (à modifier dans le module "Réassurance")



Politique retours (à modifier dans le module "Réassurance")

Demander votre devis gratuit au 0148101120
par email: sales@asinfo.com
Description
Product SKUs
SYS-E300-9D-8CN8TP
  • SuperServer E300-9D-8CN8TP (Black)

Motherboard

Super X11SDV-8C-TP8F

Processor/Cache
CPU
  • Intel® Xeon® processor D-2146NT,
    CPU TDP support 80W
Cores / Cache
  • 8 Cores, 16 Threads

System Memory
Memory Capacity
  • Up to 512GB DDR4 ECC LRDIMM
  • Up to 256GB DDR4 ECC DIMM
  • 4 DIMM slots
Memory Type
  • 2666/2400/2133MHz ECC LRDIMM and ECC DIMM
  • Operating speed up to 2400MHz
DIMM Sizes
  • RDIMM: 4GB, 8GB, 16GB, 32GB, 64GB
  • LRDIMM: 16GB, 32GB, 64GB, 128GB
Memory Voltage
  • 1.2 V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors
      (using ECC memory)

On-Board Devices
Chipset
  • System on Chip
SATA
  • SATA3 (6Gbps) ports via SoC controller
Network Controllers
  • Quad 1GbE with Intel I350-AM4
  • Dual 10GBase-T with Intel X557
  • Dual 10G SFP+ via SoC
IPMI
  • Support for Intelligent Platform
  • Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics
  • Aspeed AST2500 BMC

Input / Output
SATA
  • SoC controller for 4 SATA3 (6Gbps) ports
LAN
  • 2x 10G SFP+ ports
  • 2x 10GBase-T LAN ports
  • 4x 1GbE LAN ports
  • 1 Dedicated IPMI LAN port
USB
  • 2 USB 3.0 ports (rear)
Display
  • 1 VGA port
TPM
  • 1 TPM 2.0 header
Chassis
Form Factor
  • Compact
Model

Dimensions
Width
  • 10" (254mm) / 15" (381mm) - pkg.
Height
  • 1.7" (43mm) / 10.87" (276mm) - pkg.
Depth
  • 8.9" (226mm) / 5.59" (142mm) - pkg.
Weight
  • Gross Weight: 7.5 lbs (3.4 kg)
  • Net Weight: 3.45 lbs (1.56 kg)
Available Colors
  • Black

Front Panel
Buttons
  • Power On/Off button
LEDs
  • Power LED (Hard drive activity LED)

Expansion Slots
PCI-Express
  • 1 PCI-E 3.0 x8 slot

Drive Bays
Internal
  • 1 Fixed 2.5" drive bay with bracket (when AOC area is not occupied)

System Cooling
Fans
  • 3x 40x28mm 4-PIN PWM Fan

Power Supply
DC Power Adapter with PFC

System BIOS
BIOS Type
  • 128Mb SPI Flash with AMI BIOS
BIOS Features
  • PCI 3.0
  • ACPI 5.0
  • USB Keyboard support
  • Hardware BIOS Virus protection
  • SMBIOS 2.8
  • UEFI 2.4
  • RTC (Real Time Clock) Wakeup

Management
Software
  • Intel® Node Manager
  • IPMI 2.0
  • KVM with dedicated LAN
  • NMI
  • SUM
  • SuperDoctor® 5
  • Watch Dog
Power Configurations
  • ACPI Power Management
  • +12V DC Power Input
  • Control of power-on for recovery from AC power loss
  • CPU thermal trip support for processor protection
  • M.2 NGFF connector, Node Manager Support, SDDC, System level control, UID, WOL
Fan
  • Fans with tachometer status monitoring
  • Status monitor for speed control
  • Low noise fan speed control
  • Pulse Width Modulated (PWM) fan connectors

Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       0°C to 35°C (32°F to 95°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
Parts List
Parts List - (Items Included)
  Part Number Qty Description
Motherboard / Chassis MBD-X11SDV-8C-TP8F
CSE-E300		 1
1		 Super X11SDV-8C-TP8F Motherboard
Embedded Server BOX for Flex-ATX, Mini-ITX 1U height
Power Adapter MCP-250-10128-0N 1 150W Lockable Power Adapter with US power cord
Cooling Fan FAN-0100L4 3 4028mm 8.5K RPM 4-PIN PWM FAN
Optional Parts List
  Part Number Qty Description
Added-On-Card AOC-SLG3-2M2-O - Added-On-Card; Supports 2pcs 22x80mm or 22x110mm NVMe M.2 (Note: If the Added-On-Card is installed, no SSD can be installed then)
Riser Card RSC-RR1U-E8 - RSC-RR1U-E8 (Rev 4.00) Riser Card
Chassis Parts MCP-290-30002-0B - CSE-E300 Rackmount kit (150W/180W adapter supported)
