Médical Panel PC WMP-19K Wincomm

Wincomm With FAN Panel-PC WMP-19K Medical AI Coffee Lake 19"

  • Anti-Bacteria (MRSA) Plastic Housing & Touch
  • 19" 1280x1024 LCD Diagnostic Panel
  • Intel® 8th/9th Generation Core i5/i7 CPU
  • Supports Dual Channel DDR4 up to 64GB
  • EN/UL 60601-1 Safety & EMC Latest Version & MDR Certification Ready
  • Independent GeForce GTX 1060 Graphic Card with 6GB dedicated video memory
  • Support PCIe Expansion for Intel® Movidius™ Vision AI Card
Model WMP 19K IPOA (STD)                       　　　 WMP 19K IPOB (ISO)
Main System
CPU / Chipset Intel® 8th / 9th generation Core i7/i5 /Pentium/Celeron Processor (35W Max.)
Graphic Intel® integrated HD Graphics
RAM Two 2666/2400/2133 MHz DDR4 SODIMM socket support dual Channel, non-ECC, up to 64GB
OS Support Windows 10
Storage
M.2 M.Key 2280 PCIe X 4 NVMe SSD Up to 1TB
Optional 2.5” SATA III HDD drive bay x 1
Expansion
PCI-E (x4) x1 (25W Max.), M.2 E Key 2230 x1, Optional Network Interface: WLAN + Bluetooth module
Display Size 19” LED Backlight
Display
1280 x 1024 (SXGA), 16.7M colors, 170(H) / 160(V), 350 nits (Typ. Center point), CR:1000 : 1 (Typ)
Touch Screen Full flat projective capacitive touch panel /  Light Transmission: 90% ± 3% / Hardness: 7H pencil, pressure 750g/45° / Life: 100M times
I.O. Ports
USB USB3.1 Gen II x 4 USB3.1 Gen II x 4, ISO USB2.0 x 1
COM RS-232 x 1, RS232/RS422/RS485 X 1 ISO RS-232 x 1, ISO RS232/RS422/RS485 x 1
LAN RJ45 X 2 RJ45 X 2, ISO RJ45 x 1
Audio 3.5mm phone jack connector * 2 (Line-out, Mic-In)
Video Out DP x 2
Control Hot Key (R to L) Power Button// Audio adjustment // brightness // LCD on/off // Clean me
Mechanical and Environmental
Cooling Fan
Power Input  DC-In x 1, DC 14~19V input
Power Adapter / Battery AC input 100 ~ 240V/ 47~63 Hz/ DC output 19V/ 250W // DR-202W2
Temperature Operating Temperature: 0~40℃ / Storage Temperature: -20~60℃
Humidity Operating & Storage: 10 ~ 90%, non-condensing
IP Rating / Housing IP65 (Front Side)  IPX1 for whole system / Plastic White w/Anti-bacteria (MRSA), Housing & Touch Screen
Dimensions (Net) 450 mm (H) x 420 mm (V) x 84.1 mm (T)
Weights (Net) 7.5 KG (approximate, w/o power adapter)
Mounting Optional Stand, VESA 100
Certification
CE: EN 60601-1-2:2015(V4.0), MDR: MDR 2017/745
VCCI: 2016-11, Class B (PSU with PSE), FCC: Part 18 Class B,
UL: ANSI/AAMI ES60601-1:2012 (V3.1)
cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1)
ISO 14971 / BIS:IS13252 (Part I) / IEC60950-1
