Médical Panel PC WMP-24M-PIS WINCOMM
- Intel® Comet Lake Core i CPU
- Power Adapter Inside
- Anti-bacteria Aluminum Housing
- 23.8" FHD AHVA (IPS) Diagnostic Panel
- Optional Optical Bonding/AG Film
- Optional Full HD Capture Card
- LAN/COM 4KV Isolated Module
- Optional DICOM Part 14
- Support Video-In with Color Adjustment
- Support DP x 1, HDMI x 1 for Extended Display Output
- Support Windows 11 & fTPM
Medical OR All In One PC
Integrated with Built-in Power Supply, Secure Operation Procedure
Medical OR All In One PC series is designed for operating room applications, such as endoscopic surgery, robotic surgery, and so on. With anti-bacteria elegant aluminum housing, it supports full sealed waterproof for IP65 whole system, and two display port output, one unique video-input function to receive medical capture devices for all types of minimally invasive surgery. The special power adapter inside design is featuring at clean and easy installation to secure operating safety.
. - Anti-Bacteria (MRSA) Housing stands up to Chemical Disinfection
These medical cart computers have an special antimicrobial housing to battle surface contamination (MRSA), an IP65 rated sealed front bezel and six side IP65 with I.O. cover making it easy to clean and disinfect. - Global Latest UL/cUL 60601-1 (MDR) and IEC60601-1 Medical Certifications
Medical grade, and certified to be safe for near patient use. These computers were designed from the ground up to meet global medical safety standards. - 10th Gen Intel Core CPU
Our medical panel pcs offer the Comet Lake 10th generation Intel® Core i3/i5/i7 processor series. Other features listed below:
- Support Intel® Vpro Technology by CPU suit for intelligent remote control SW management,
- FHD video real-time streaming to support hospital theatre on real-time surgical imaging needs.
- 23.8" FHD MVA/AHVA Diagnostic Panel
- Optional Full HD Capture Card & HDMI Video-In
- LAN/COM 4KV Isolated Module
- Power Adapter Inside for WMP-24M-PIS
- Optional DICOM Part 14 Compliance Solution
- Support Windows 11 & fTPM
- Optional Internal UPS Battery pack (WMP-24M)
Specification
| MDR (2017/745) By ProjectModel | WMP-24M-PIS IPOA (STD) | WMP-24M-PIS IPOB (ISO) |
|---|---|---|
| Main System | ||
| CPU / Chipset | LGA1200 package 10th gen Intel® Core i7/i5/i3/Pentium/Celeron processor (35W max.) Intel® Q470E Chipset (Intel® PCH) | |
| Graphic | Intel® integrated UHD Graphics by CPU | |
| RAM | 2 x 260-pin SO-DIMM, Dual Channel DDR4 2933 / 2666 / 2400 MHz, up to 64GB | |
| OS Support | Optional Win 10 IoT Enterprise LTSC 64 bit, Windows 11 IoT Enterprise GAC 64 bit | |
| Storage | 1 x M.2 (M Key, 2280) with NVMe PCIe x4 & SATA3 for SSD, 1 x 2.5” SATA3 HDD/SSD | |
| Expansion | 1 x PCI-E x16(20W Max.), 1x M.2 E key 2230, 1x M.2 (B/M Key, 2242/2260/2280) with PCIex1 | |
| Display Size | 23.8” 16:9 | |
| Display | 1920 x 1080 (Full HD), 16.7M colors,178(H) / 178(V), 400 nits (Typ. Center point), CR:1000 : 1 (Typ) | |
| Touch Screen | Full flat projective capacitive touch panel / Light Transmission: 85% ± 3% / Hardness: 6H pencil, pressure 750g/45° / Life: 100M times | |
| I.O. Ports | ||
| USB | 4 x USB 3.2 gen 2 | 4 x USB 3.2 gen 2 |
| COM | 1 x RS232, 1 x RS232/RS422/RS485 | 1 x ISO RS232/RS422/RS485 |
| LAN | 1 x RJ45 1Gbps Intel® I219LM (AMT/Vpro) 1 x RJ45 2.5Gbps Intel® I225V | 1 x RJ45 1Gbps Intel® I219LM (AMT/Vpro) 1 x RJ45 2.5Gbps Intel® I225V 1 x ISO RJ45 1Gbps |
| Audio | 3.5mm phone jack connector * 2 (Line-out, Mic-In) | |
| Video Out | 1 x DP 1.2 / DP++,1 x HDMI 1.4a | |
| Video In | 1 x HDMI-in | |
| Control Hot Key (L to R) | Battery LED Indicator; Power; Menu/Exit; Brightness; Video-In LCD On/Off; Clean Me; Programmable Function | |
| Mechanical and Environmental | ||
| Cooling | Fanless | |
| Power Adapter | 100-240VAC,47~63HZ, DC Output 24V, 250W (Internal Medical Grade PSU) | |
| Temperature | Operating Temperature: 0~35℃ / Storage Temperature: -20~60℃ | |
| Humidity | Operating & Storage:10 ~ 90%, non-condensing | |
| IP Rating | IP65 at front side, Full IP65 w/optional I.O. cover / Touch (standard)/ Glass(customized); | |
| Housing | Rear: Aluminum Alloy Body / White (Touch) | |
| Dimensions (Net) | 580mm (H) x 350mm (V) x 59mm (T) | |
| Weights (Net) | 11.2 kg (w/o power adapter/battery pack) | |
| Mounting | VESA 100 x 100 | |
| Certification | FCC (part 18 Class B) / CE (EN 60601-1-2 :2015 ver. 4.0) / VCCI (2016-11, class B) UL(ES60601-1:2012 (V3.1) / cUL (C22.2 No. 60601-1:2014 V3.1) MDR (2017/745), ISO 14971/ IEC 62133 | |
